to crop the rgb image based on the pixel value

Question

I am having an rgb image and I want to crop it from all sides. i have tried the below code on gray scale image it works but for RGB image it doesn't. My code is:

    import cv2
    import numpy as np
    import glob,os
    from PIL import Image

    inputdir = "/Users/sripdeep/Desktop/Projects/3 Norm_Sub_Norm/rgb/"
    outpath = "/Users/sripdeep/Desktop/Projects/3 Norm_Sub_Norm/rgb_norm/"

    #filesname = sorted(glob.glob( inputdir + "*.jpg"))

    for img1 in sorted(glob.glob( inputdir + "*.jpeg")):

        img_path = img1.split('/')[-1]
        imgstr = img_path.split('.')[0]

        print(imgstr)
        im1 = cv2.imread(img1,0)
        thresh = cv2.threshold(im1, 100, 255, cv2.THRESH_BINARY)[1]
        x, y, w, h = cv2.boundingRect(im1)           #  calculates nonzero pixels
#        print(x,y,w,h)
#        a tuple (x, y, w, h) with (x, y) the upper left point
#        as well as width w and height h of the bounding rectangle.

        left = (x, np.argmax(thresh[:, x]))             #
        right = (x+w-1, np.argmax(thresh[:, x+w-1]))    #
        top = (np.argmax(thresh[y, :]), y)              #
        bottom = (np.argmax(thresh[y+h-1, :]), y+h-1)

        print('left: {}'.format(left))
        print('right: {}'.format(right))
        print('top: {}'.format(top))
        print('bottom: {}'.format(bottom))

#        cropped__img = img[y1:y2, x1:x2]
        cropped__img = thresh[top[1]:bottom[1], left[0]:right[0]]
        cropped__img = cv2.resize(cropped__img, (256,256), interpolation=cv2.INTER_LINEAR)

        save_fname = os.path.join(outpath, os.path.basename(imgstr)+'.jpg')
        cv2.imwrite(save_fname, cropped__img)

I want my image to be cropped like this:

But I get output is:

score 3 · Accepted Answer · answered Jun 25 '20 at 05:06

Your approach is close, and can be simplified a bit.

Note that cv2.boundingRect(..) can only be applied on single channel images. Because of this, it seems easiest to first read a color image, then convert it to grayscale to figure out bounding rectangle (x,h,w,h) coordinates (x1, y1, x2, y2), and then apply cropping to the original color image. Perhaps something like this:

im1 = cv2.imread(img1,0) # color image
im1_gray = cv2.cvtColor(im1, cv2.COLOR_BGR2GRAY) # grayscale
thresh = cv2.threshold(im1_gray, 100, 255, cv2.THRESH_BINARY)[1] # threshold image
x, y, w, h = cv2.boundingRect(thresh) # find the bounding rectangle of nonzero points in the image
cropped__img = im1[y:y+h, x:x+w,:] # crop the original color image

score 0 · Answer 2 · answered Jun 25 '20 at 05:10

This one is pretty straightforward. A color image in OpenCV in Python is a 3-dimensional NumPy array (x, y, color). A grayscale image is a 2-dimensional array (x, y).

In this line, you are cropping a grayscale (2D) image by giving limits on the x and y dimensions:

cropped__img = thresh[top[1]:bottom[1], left[0]:right[0]]

see this answer for more info on slice notation in Python. To crop a color image, you need to tell Python to grab everything in the third dimension by using simply :

#                                                      v
cropped__img = img[top[1]:bottom[1], left[0]:right[0], :]
