Android: Add neon glow effect to button

Question

I want to have a glow effect on button (in android studio) as shown in image:

I didn't want an image for the background, so to get this effect, I have tried to do in xml file. I have added a stroke for the button and provide a shadow to the button (with same color as stroke).

I have used a linear gradient with 90 degree angle with start and end color same as the stroke, center color same as background color. Please see the code:

<?xml version="1.0" encoding="utf-8"?>
<selector xmlns:android="http://schemas.android.com/apk/res/android">
<item>
    <layer-list>
        <item android:right="5dp" android:top="0dp">
            <shape>
                <corners android:radius="50dp" />
                <gradient
                    android:angle="45"
                    android:startColor="#8008c3fa"
                    android:endColor="#8008c3fa"
                    android:type="linear"
                    />
            </shape>
        </item>
        <item android:bottom="5dp" android:left="6dp" android:right="10dp" android:top="5dp">
            <shape xmlns:android="http://schemas.android.com/apk/res/android" android:shape="rectangle" >
                <corners
                    android:radius="50dp"
                    />
                <gradient
                    android:angle="90"
                    android:centerX="50%"
                    android:centerColor="@color/trans_parent"
                    android:startColor="#8008c3fa"
                    android:endColor="#8008c3fa"
                    android:type="linear"
                    />
                <padding
                    android:left="0dp"
                    android:top="0dp"
                    android:right="0dp"
                    android:bottom="0dp"
                    />
                <size
                    android:width="270dp"
                    android:height="60dp"
                    />
                <stroke
                    android:width="2.5dp"
                    android:color="#08c3fa"
                    />
            </shape>
        </item>
    </layer-list>
</item>

</selector>

For the above xml, I got the below result:

Though the design and the result images look totally different, I think if we increase the center color height and keep a fadeout effect to the shadow, it can work. But I'm not able to do the same.

you can design one by using Figma or Adobe XD, and use the asset as a button — Ali, Sep 20 '20 at 10:31
@Ali, thanks for the reply. But can't we do it using xml itself? — Sri Harsha, Sep 20 '20 at 10:44
I haven't tried such level of gradients in android, So to be honest I really dont know if its possile — Ali, Sep 20 '20 at 10:45

MehranB · Answer 1 · 2021-04-11T08:33:41.170

7

I know it has been a while but if anyone is still interested in this effect, here is a custom view library I made which was inspired by this question:

Glowing and Neon Button

It also has animated disable and enable methods as seen in the photo.

It's MIT Licensed, so do whatever you want with it. hope this helps someone.

edited Apr 11 '21 at 08:33

answered Apr 10 '21 at 20:58

MehranB

1,460
2
7
17

how we can we keep animating the glow ? – Zeeshan Ali Jul 27 '22 at 09:52
@ZeeshanAli You can't. this is the animation for enabling/disabling the button. – MehranB Jul 28 '22 at 05:28

score 5 · Answer 2 · answered Dec 13 '20 at 23:16

you can increase the center color height and keep a fadeout effect to the shadow by adding a nother item to the layer-list. The first item makes the gradient for the upper bound, the rest is transparent and the second item makes the gradient for the lower bound the same way.

I added two more items to fill the left and the right semicircle. I changed a few colours to enhance the effect but didnt trie too long, i think one could do alot more with more items and better colours :)

Cheers, Josh

the final result:

    <?xml version="1.0" encoding="utf-8"?>
<selector xmlns:android="http://schemas.android.com/apk/res/android">
    <item>
        <layer-list>
            <item android:right="5dp" android:top="0dp">
                <shape>
                    <corners android:radius="50dp" />
                    <gradient
                        android:centerX="70%"
                        android:startColor="#804CD6FF"
                        android:centerColor="#8004485C"
                        android:endColor="#804CD6FF"
                        android:type="linear"
                        />
                </shape>
            </item>
            <item android:bottom="5dp" android:left="6dp" android:right="10dp" android:top="5dp">
                <shape xmlns:android="http://schemas.android.com/apk/res/android" android:shape="rectangle" >
                    <corners
                        android:radius="50dp"
                        />
                    <gradient
                        android:angle="90"
                        android:centerX="30%"
                        android:centerColor="@color/transparent"
                        android:startColor="#8008c3fa"
                        android:endColor="@color/transparent"
                        android:type="linear"
                        />
                    <size
                        android:width="270dp"
                        android:height="60dp"
                        />
                    <stroke
                        android:width="2.5dp"
                        android:color="#08c3fa"
                        />
                </shape>
            </item>
            <item android:bottom="5dp" android:left="6dp" android:right="10dp" android:top="5dp">
                <shape xmlns:android="http://schemas.android.com/apk/res/android" android:shape="rectangle" >
                    <corners
                        android:radius="50dp"
                        />

                    <gradient
                        android:angle="90"
                        android:centerX="70%"
                        android:centerColor="@color/transparent"
                        android:startColor="@color/transparent"
                        android:endColor="#8008c3fa"
                        android:type="linear"
                        />

                    <size
                        android:width="270dp"
                        android:height="60dp"
                        />
                </shape>
            </item>
            <!-- the glow for the half circles, possible with radius as well. I liked
                 android:type="sweep" better because radius tends to fade out.-->
            <item android:bottom="5dp" android:left="6dp" android:right="10dp" android:top="5dp">
                <shape xmlns:android="http://schemas.android.com/apk/res/android" android:shape="rectangle" >
                    <corners
                        android:radius="50dp"
                        />

                    <gradient
                        android:angle="360"
                        android:centerX="5%"
                        android:centerColor="#8008c3fa"
                        android:startColor="@color/transparent"
                        android:endColor="@color/transparent"
                        android:gradientRadius="360"
                        android:type="sweep"
                        />

                    <size
                        android:width="270dp"
                        android:height="60dp"
                        />
                </shape>
            </item>
            <item android:bottom="5dp" android:left="6dp" android:right="10dp" android:top="5dp">
                <shape xmlns:android="http://schemas.android.com/apk/res/android" android:shape="rectangle" >
                    <corners
                        android:radius="50dp"
                        />

                    <gradient
                        android:angle="360"
                        android:centerX="95%"
                        android:centerColor="@color/transparent"
                        android:startColor="#8008c3fa"
                        android:endColor="#8008c3fa"
                        android:gradientRadius="360"
                        android:type="sweep"
                        />

                    <size
                        android:width="270dp"
                        android:height="60dp"
                        />
                </shape>
            </item>
        </layer-list>
    </item>

</selector>

score 2 · Answer 3 · answered Jul 30 '21 at 00:51

If you want to have improved neon Buttons with a solid that has different gradients too. Take a look on this related post I answered. I used the suggested library from "@Mehran B" and combined it with a custom drawable and a transparent stroke to make it more modifiable. As you can see in the samples below the gradients from the solids and shadows are separated and thus more flexible:
