AADSTS9002325: Proof Key for Code Exchange is required for cross-origin authorization code redemption

Question

I created a spa application owned by my organization only, but there was a problem when I requested code. How can I resolve it?

Answer 1

I can reproduce your problem, you have to add the redirect URL under the web (not single page application). After that, you will be able to use the auth code flow to get the code.

Similar problem，see: here and here and here.

Answer 2

There is a problem with the accepted answer: The question was for SPA WEB, but the proposed solution was to change it to SSR WEB

For ssr webs, the flow used is called OAuth 2.0 authorization code flow in which a code is sent from microsoft after the success login (302 redirect) and the this code is exchanged for a new access_token (microsoft internal apis).

For spa webs, in which sometimes there is no a programmable backend server serving the web files (index.html, js, css) able to receive the code and exchange it for an access_token. The flow used is called OAuth 2.0 implicit grant flow in which ID tokens or access tokens are returned directly from microsoft after the success login (302 redirect)

Note: Implicit grant flow is being deprecated in some IAM platforms

If you are developing a spa web with pure react, angular,vue, etc instead of ssr web with java, c#, php, etc or hybrids like nuxt, next, etc and you need the access_token instead the auth code (ssr) you should follow these steps:

Step 1

Register your app as admin or a simple user

https://portal.azure.com/#blade/Microsoft_AAD_RegisteredApps/ApplicationsListBlade

Step 2

add a web platform type SPA with the redirect to your spa

Step 3

Check the access token checkbox

Step 4

In this step, you should be able to obtain the classic values (google, facebook, microsoft, etc) for this kind of login: clientid, clientsecret, reduirect_uri, tenant, etc

Step 5

At the spa source code layer, change the response_type=code to response_type=token in your authorize url

https://login.microsoftonline.com/{tenant}/oauth2/v2.0/authorize?
client_id=6731de76-14a6-49ae-97bc-6eba6914391e
&response_type=token
&redirect_uri=http%3A%2F%2Flocalhost%2Fmyapp%2F
&scope=openid
&response_mode=query

Additional

If everything works, all of your final users will be prompted with something like this at the login step:

Yes, this is another "Azure feature". Anyway who told you to use Microsoft tools ??

To avoid that, with the admin help, approve it or follow these infinite steps to mark your app as verified

References:

• https://developer.okta.com/blog/2018/04/10/oauth-authorization-code-grant-type
• https://developer.okta.com/blog/2018/05/24/what-is-the-oauth2-implicit-grant-type
• https://learn.microsoft.com/en-us/azure/active-directory/develop/v2-oauth2-implicit-grant-flow
• https://learn.microsoft.com/en-us/power-apps/developer/data-platform/walkthrough-register-app-azure-active-directory

Answer 3

Don't know if I am late but I've had the same issue in my React SPA Application and the solutions wasn't to change my app to Web in Portal, it was solving the actual problem which was there was no proof key in my request. I've solved it by my making helper functions and adding this in url where I send users to authenticate:

function buildAuthorizationUrl(codeChallenge) {
    const clientId = "YOUR_CLIENT_ID":
    const redirectUri = encodeURIComponent("http://localhost:5173/auth/");
    // Change to url you need
    const responseType = "code";
    const scope = encodeURIComponent("openid profile offline_access User.Read");
    const state = encodeURIComponent("my_custom_state");
    return `https://login.microsoftonline.com/common/oauth2/v2.0/authorize?client_id=${clientId}&response_type=${responseType}&redirect_uri=${redirectUri}&scope=${scope}&state=${state}&code_challenge=${codeChallenge}&code_challenge_method=S256`;
    }
async function generateCodeVerifier() {
  const array = new Uint8Array(32);
  crypto.getRandomValues(array);
  return Array.from(array)
    .map((b) => b.toString(16).padStart(2, "0"))
    .join("");
}

async function generateCodeChallenge(codeVerifier) {
  const encoder = new TextEncoder();
  const data = encoder.encode(codeVerifier);
  const digest = await crypto.subtle.digest("SHA-256", data);

  const base64Url = (arrayBuffer) => {
    const base64 = btoa(String.fromCharCode(...new Uint8Array(arrayBuffer)));
    return base64.replace("+", "-").replace("/", "_").replace(/=+$/, "");
  };

  return base64Url(digest);
}

And then when user clicks the button for logging I've added this logic:

  const handleClick = async () => {
    const codeVerifier = await generateCodeVerifier();
    const codeChallenge = await generateCodeChallenge(codeVerifier);
    sessionStorage.setItem("code_verifier", codeVerifier);
    const authUrl = buildAuthorizationUrl(codeChallenge);
    window.location.href = authUrl;
  };

Of course, if you are not dealing with common tenant, that should also be changed in buildAuthorizationUrl function.

Answer 4

I have created same spa application in my organization and created same redirect uri for SPA, since it is inside organization so i did not have access to change configuration for the existing app. It may not be ideal for some cases. I have solved it by sending PKCE information for auth and token request as described in OAuth . First generate code_verifier from random string then generate code_challenge using code_verifier.

You need to Add code_challenge in your request for authorization_code along with code_challenge_method:S256 (SHA256). For token code_verifier needs to be sent for token request. Curl Request sample is given below,

Authorization curl --location --request GET 'https://login.microsoftonline.com/<tenat_id>/oauth2/v2.0/authorize?client_id=<client_id>&redirect_uri=<redirect_uri>&scope=<scope>&response_type=code&response_mode=query&sate=demo&code_challenge=<code_challenge>&code_challenge_method=S256'

Token

curl --location --request POST 'https://login.microsoftonline.com/<tenat_id>/oauth2/v2.0/token --form 'code_verifier=<code_verifier>
