Can I keep bar width constant in R facet plot with different number of categories in each facet?

Question

I hope somebody can help me with my problem:

My data consists of categories that contain a number of up-regulated and down-regulated genes. I want them to show as horizontal, stacked columns. That works
I sorted generated these gene categories with two methods (Terms), UP_Keyword and GO-Term. They yielded different numbers of gene categories. No problem with facet wrap.

# A tibble: 10 x 4
   Category             Term       Reg   Reg_val
   <chr>                 <chr>      <chr>   <dbl>
 1 Transport            UP_Keyword Up         63
 2 Transmembrane helix  UP_Keyword Up        341
 3 Transmembrane        UP_Keyword Up        344
 4 Transport            UP_Keyword Down        3
 5 Transmembrane helix  UP_Keyword Down       12
 6 Transmembrane        UP_Keyword Down        9
 7 translation          GO_term    Up         41
 8 glycolytic process   GO_term    Up          9
 9 translation          GO_term    Down        0
10 glycolytic process   GO_term    Down        1

structure(
  list(
    Category = c(
      "Transport",
      "Transmembrane helix",
      "Transmembrane",
      "Transport",
      "Transmembrane helix",
      "Transmembrane",
      "translation",
      "glycolytic process",
      "translation",
      "glycolytic process"
    ),
    Term = c(
      "UP_Keyword",
      "UP_Keyword",
      "UP_Keyword",
      "UP_Keyword",
      "UP_Keyword",
      "UP_Keyword",
      "GO_term",
      "GO_term",
      "GO_term",
      "GO_term"
    ),
    Reg = c(
      "Up",
      "Up",
      "Up",
      "Down",
      "Down",
      "Down",
      "Up",
      "Up",
      "Down",
      "Down"
    ),
    Reg_val = c(63, 341, 344, 3, 12,
                9, 41, 9, 0, 1)
  ),
  row.names = c(NA,-10L),
  class = c("tbl_df",
            "tbl", "data.frame")
)

ex_plot <- ggplot(example_data, aes(x=Reg_val, y=Category, fill=Reg))+
  geom_col(width=0.5)+
  facet_wrap(.~Term, nrow=2, scales="free")

This is how my plot looks now

I want the bars to be the same width in all facets. Is there a way to do that?
I found a possible solution here:https://community.rstudio.com/t/preserve-constant-bar-widths-for-uneven-faceted-plots/26837 However, simply adding space="free" inside facet_wrap() results in no changes but a warning: unused argument (space = "free")

If someone has a solution for my problem, I would be very grateful. Please try to explain in a way a simple biologist can understand.

Please share your example data as a `dput()` so we can copy/paste into R for testing. See [how to make a reproducible example](https://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example) — MrFlick, Jan 03 '21 at 08:41

score 3 · Accepted Answer · answered Jan 03 '21 at 08:44

The facet_wrap() way of specifying facets doesn't allow for the space = "free" argument; this is an argument to facet_grid().

Depending where you want the strip labels/facet titles to be, you can either use facet_grid() or use facet_row() from the ggforce package. Examples below.

library(ggplot2)

df <- data.frame(
  Category = c("Transport", "Transmembrane helix", "Transmembrane",
               "Transport", "Transmembrane helix", "Transmembrane",
               "translation", "glycolytic process",
               "translation", "glycolytic process"),
  Term = rep(c("UP_Keyword", "GO_term"), c(6, 4)),
  Reg = rep(c("Up", "Down", "Up", "Down"), c(3, 3, 2, 2)),
  Reg_val = c(63, 341, 344, 3, 12, 9, 41, 9, 0, 1)
)

# Make the core plot
plot <- ggplot(df, aes(Reg_val, Category, fill = Reg)) +
  geom_col(width = 0.5)

plot + facet_grid(Term ~ ., scales = "free", space = "free")

plot + ggforce::facet_col(~ Term, space = "free", scales = "free_y")

^{Created on 2021-01-03 by the reprex package (v0.3.0)}
