ggplot2 geom_bar color bars by one column and outline by another column

Question

My dataframe has the following columns:

Proportion, which is the y axis.
Category, which is the x axis and have 7 categories
Group1, which is binary
Group2, which has 4 groups, multiple categories could belong to a same group.

I wish to color the bars by Group2 (so fill = Group2), but I couldn't figure out how to make bars outlined or not based on Group1 as well. My current code is

  ggplot(data=df, aes(x=Category,y=Proportion, fill = Group1, group = Group2)) +
    geom_bar(stat = "identity", position = position_dodge()) +
    xlab("") +
    ylab("Proportion") +
    theme_classic() +
    theme(legend.position="top") +
    theme(legend.title = element_blank())

I am new to R visualization, so it would be really nice if someone could tell me how to outline the bars based on the grouping.

Here's how the dataframe should look like:

> df
   Category Proportion Group1 Group2
1         1          45      a      A
2         2          40      a      A
3         3          49      a      A
4         4          47      a      A
5         5          43      a      A
6         1          32      a      B
7         2          37      a      B
8         3          45      a      B
9         4          47      a      B
10        5          50      a      B
11        6          49      b      A
12        7          34      b      A
13        8          31      b      A
14        6          36      b      B
15        7          46      b      B
16        8          39      b      B
17        9          42      c      A
18        9          31      c      B
19       10          31      d      A
20       10          44      d      B

Here's the current output:

output

I want the bars on left of each group to be outlined (white filling and the edge be the same color as the group)

It would be easier to help if you create a small reproducible example along with expected output. Read about [how to give a reproducible example](http://stackoverflow.com/questions/5963269). — Ronak Shah, May 14 '21 at 01:51
I do want the bars in each group to be side by side, not stacked. — Irio Li, May 14 '21 at 01:52
What color do you want to make the outlines? I'm not clear what your desired output us here. Just like solid black? You can set `geom_bar(stat = "identity", position = position_dodge(), color="black")` It's hard to help when we have no idea what the plot currently looks like. A [reproducible example](https://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example) would be very helpful. — MrFlick, May 14 '21 at 01:52
Hi, Please see the update for a toy example and my current output. Thanks! — Irio Li, May 14 '21 at 02:16

Ian Campbell · Accepted Answer · 2021-05-14T03:23:29.827

Is this what you're looking for?

Set fill to Group2 then color to Group1. You can override the legend if you want a particular color or fill. I added factor around Category to get the x axis to make more sense, although I suspect your actual Category is already a factor.

Note your data column is Proportions, although your code is Proportion.

ggplot(data=df, aes(x=factor(Category),y=Proportions, fill = Group2, color = Group1)) +
    geom_bar(stat = "identity", position = position_dodge()) +
    scale_fill_manual(values =c(A = "white", B = "gray")) +
    xlab("") + ylab("Proportion") +
    theme_classic() +
    theme(legend.position="top") +
    theme(legend.title = element_blank()) +
    guides(fill = guide_legend(override.aes =
                               list(color = "gray")),
           color = guide_legend(override.aes =
                               list(fill = "gray")))

If you're dead set on the fill matching the color, it gets more complicated, but you can use interaction(Group2,Group1) as the fill. Then you have to manually determine the colors for the interactions.

ggplot(df, aes(x=factor(Category),y=Proportions, fill = interaction(Group2,Group1), color = Group1)) +
    geom_bar(stat = "identity", position = position_dodge()) +
    scale_fill_manual(values = setNames(c(rep("white",4),"cornflowerblue","forestgreen","firebrick3","goldenrod"),
                                        sort(unique(as.character(interaction(df$Group2,df$Group1))))),
                      breaks = c("A.a","B.a"),
                      labels = c("A","B")) +
    scale_color_manual(values = setNames(c("cornflowerblue","forestgreen","firebrick3","goldenrod"),
                                         sort(unique(as.character(df$Group1))))) +
    labs(x = "", y = "Proportion") +
    theme_classic() +
    theme(legend.position="top") +
    theme(legend.title = element_blank()) +
    guides(fill = guide_legend(override.aes =
                               list(color = "gray",
                                    fill = c("white","darkgray"))),
           color = guide_legend(override.aes =
                               list(fill = c("white"))))

To understand what's going on here, consider this:

interaction(df$Group2,df$Group1)
[1] A.a A.a A.a A.a A.a B.a B.a B.a B.a B.a A.b A.b A.b B.b B.b B.b A.c B.c A.d B.d
Levels: A.a B.a A.b B.b A.c B.c A.d B.d

If we sort and unique this, we get the following:

sort(unique(as.character(interaction(df$Group2,df$Group1))))
[1] "A.a" "A.b" "A.c" "A.d" "B.a" "B.b" "B.c" "B.d"

We want the first 4 to be white, so we can use rep, and then manually define the others.

c(rep("white",4),"cornflowerblue","forestgreen","firebrick3","goldenrod")
[1] "white"          "white"          "white"          "white"          "cornflowerblue" "forestgreen"    "firebrick3"     "goldenrod"

From here we can use setNames to apply the fills to the values:

setNames(c(rep("white",4),"cornflowerblue","forestgreen","firebrick3","goldenrod"),
                                         sort(unique(as.character(interaction(df$Group2,df$Group1)))))
             A.a              A.b              A.c              A.d              B.a              B.b              B.c              B.d
         "white"          "white"          "white"          "white" "cornflowerblue"    "forestgreen"     "firebrick3"      "goldenrod"

Repeat the process for the colors.

We don't necessarily want to see all of the interaction()'s in the legend. So we can limit them with the breaks = argument. We can rename A.a and B.a to just A and B with labels =.

1

This looks awesome! Thanks! – Irio Li May 14 '21 at 03:22
