R Pre/Post Drop Lines Scatterplot

Question

Is there a way to create a scatter plot with paired points. For example, I have 50 patients with preoperative and postoperative BMI values. I want to visualize each of these points on a vertical line so the change is clear. I have tried ggpaired function but this just creates a chart with differing conditions. The conditions would be the same.

Hybrid ScatterPlot:

It's easier to help you if you include a simple [reproducible example](https://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example) with sample input that can be used to test and verify possible solutions. — MrFlick, Jun 22 '21 at 20:53

score 0 · Accepted Answer · answered Jun 22 '21 at 21:03

I'm guessing your data looks similar to this random patients example

library(tidyverse)

patients <- tibble(
    id = rep(1:50, each = 2),
    group = rep(c("Placebo", "Treatment"), each = 50),
    stage = rep(c("Pre", "Post"), times = 50),
    measurement = rnorm(100)
)

patients
#> # A tibble: 100 x 4
#>       id group   stage measurement
#>    <int> <chr>   <chr>       <dbl>
#>  1     1 Placebo Pre       -0.710
#>  2     1 Placebo Post      -1.20
#>  3     2 Placebo Pre       -0.513
#>  4     2 Placebo Post      -0.0675
#>  5     3 Placebo Pre       -0.346
#>  6     3 Placebo Post       0.467
#>  7     4 Placebo Pre        0.626
#>  8     4 Placebo Post       0.884
#>  9     5 Placebo Pre        0.0290
#> 10     5 Placebo Post       1.43
#> # ... with 90 more rows

A simple approach with ggplot2 would be something like this

ggplot(patients, aes(id, measurement)) +
    geom_line(aes(group = id, color = group))

^{Created on 2021-06-22 by the reprex package (v2.0.0)}
