SwiftUI DatePicker breaks sheet dismiss?

Question

Scenario:

RootScreen presents DateScreen modally though .sheet
DateScreen has a DatePicker with CompactDatePickerStyle() and a button to dismiss the modal
User opens the DatePicker
User taps the DatePicker to bring up the NumPad for manual keyboard input
User presses the button to dismiss the modal

SwiftUI will think the .sheet got dismissed, but in reality, only the DatePicker's modal got dismissed.

Minimum code example:

struct DateScreen: View {
    @Binding var isPresented: Bool
    @State var date: Date = Date()

    var body: some View {
        NavigationView {
            VStack {
                DatePicker("", selection: $date, displayedComponents: [.hourAndMinute])
                    .datePickerStyle(CompactDatePickerStyle())
            }
            .navigationBarItems(leading: Button("Dismiss") {
                isPresented = false
            })
        }
    }
}

@main
struct Main: App {
    @UIApplicationDelegateAdaptor(AppDelegate.self) var appDelegate
    @State var isPresenting: Bool = false

    var body: some Scene {
        WindowGroup {
            Button("Present modal", action: {
                isPresenting = true
            })
                .sheet(isPresented: $isPresenting, content: {
                    DateScreen(isPresented: $isPresenting)
                })
        }
    }
}

Gif showing the broken behavior:

Note, if the user doesn't open the NumPad, it seems to work well.

Likely has to do with the whole root view controller thing (everything presents there). If you use `.adaptiveSheet` from [here](https://stackoverflow.com/questions/56700752/swiftui-half-modal/67994666#67994666) instead it works fine. Likely not a solution. — lorem ipsum, Dec 19 '21 at 20:01
This also breaks the latest (iOS15) SwiftUI `@Environment(\.dismiss)` dismiss action. — Andrew Tetlaw, Jan 02 '22 at 01:06
I should also add, that it works fine in the iOS simulator. Seems to only be a problem on a device. — Andrew Tetlaw, Jan 02 '22 at 01:13

score 1 · Answer 1 · answered Dec 19 '21 at 18:38

1

The only workaround I found is to ignore SwiftUI and go back to UIKit to do the dismissal.

Instead of isPresented = false I have to do UIApplication.shared.windows.first?.rootViewController?.dismiss(animated: true).

answered Dec 19 '21 at 18:38

Lord Zsolt

6,492
9
46
76

This isn't really a great solution because if you have multiple layers of sheets it will dismiss all of them, not only the topmost one where the date picker is. – axlrtr Mar 27 '23 at 01:08

score 1 · Answer 2 · answered May 09 '22 at 00:34

1

For iOS 15 this works to dismiss the sheet and doesn't generate the warning:

'windows' was deprecated in iOS 15.0: Use UIWindowScene.windows on a relevant window scene instead

code:

UIApplication.shared.connectedScenes
    .filter({$0.activationState == .foregroundActive})
    .compactMap({$0 as? UIWindowScene})
    .first?
    .windows
    .first { $0.isKeyWindow }?
    .rootViewController?
    .dismiss(animated: true)

answered May 09 '22 at 00:34

Benson Wong

631
6
5

This isn't really a great solution because if you have multiple layers of sheets it will dismiss all of them, not only the topmost one where the date picker is. – axlrtr Mar 27 '23 at 01:07
Add .presentedViewController? before dismiss and it will only dismiss the topmost sheet. – axlrtr Apr 17 '23 at 00:18

Asperi · Accepted Answer · 2022-07-14T04:03:42.167

1

This is problem of provided code - the State is in Scene instead of view - state is not designed to update scene. The correct SwiftUI solution is to move everything from scene to a view and have only one root view there, ie.

Tested with Xcode 13.4 / iOS 15.5

@main
struct Main: App {
    @UIApplicationDelegateAdaptor(AppDelegate.self) var appDelegate

    var body: some Scene {
        WindowGroup {
           ContentView()    // << window root view, the one !!
        }
    }
}


struct ContentView: View {
    @State var isPresenting: Bool = false

    var body: some View {
        Button("Present modal", action: {
            isPresenting = true
        })
        .sheet(isPresented: $isPresenting, content: {
            DateScreen(isPresented: $isPresenting)
        })

    }
}

// no more changes needed

edited Jul 14 '22 at 04:03

answered Jul 12 '22 at 12:24

Asperi

228,894
20
464
690

@MehulThakkar, here is a correct approach. – Asperi Jul 12 '22 at 12:37
what’s the point of isPresenting in Main? It doesn’t seem to be used anywhere. – Lord Zsolt Jul 13 '22 at 22:34
@LordZsolt, No use, just remained on copy-paste from original - removed. Thanks. – Asperi Jul 14 '22 at 04:04
@Asperi: It worked, just taking out datepicker as view worked fine. – Mehul Thakkar Jul 15 '22 at 13:06
