Bottom item cut in reyclerview in android

Question

Hey I am working in constraint layout with recylerview. My bottom item is cut in the screen. I read this stack overflow post. I don't want to use relative layout or linear layout. Can someone guide me how to fix this in constraint layout.

abc.xml

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <androidx.appcompat.widget.SearchView
        android:id="@+id/searchView"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginStart="10dp"
        android:layout_marginTop="10dp"
        android:layout_marginEnd="16dp"
        app:closeIcon="@drawable/ic_cancel"
        app:layout_constraintBottom_toTopOf="@+id/exploreScroll"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent"
        app:layout_constraintVertical_chainStyle="packed"
        app:layout_constraintVertical_bias="0.0" />

    <HorizontalScrollView
        android:id="@+id/exploreScroll"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginStart="10dp"
        android:layout_marginTop="10dp"
        android:scrollbars="none"
        app:layout_constraintBottom_toTopOf="@+id/exploreList"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toBottomOf="@+id/searchView">

        <com.google.android.material.chip.ChipGroup
            android:id="@+id/exploreChips"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            app:chipSpacingHorizontal="10dp"
            app:layout_constraintLeft_toLeftOf="parent"
            app:layout_constraintTop_toTopOf="parent"
            app:singleLine="true"
            app:singleSelection="true" />

    </HorizontalScrollView>

    <androidx.recyclerview.widget.RecyclerView
        android:id="@+id/exploreList"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginBottom="20dp"
        android:paddingTop="10dp"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toBottomOf="@+id/exploreScroll" />

</androidx.constraintlayout.widget.ConstraintLayout>

My view cut from

UPDATE

@Zain after your suggestion i tried in my xml any my HorizontalScrollView is going behind my RV. I am adding my blueprint and you can see clearly that, HorizontalScrollView is going behind. After removing app:layout_constraintBottom_toTopOf="@+id/exploreList" from the HorizontalScrollView.

2nd suggestion try

Answer 1

Disclaimer Using a wrap_content height with vertical RecyclerView can have impact on performance in terms of recycling views; specially if the height is going to change frequently. Check this article for more illustration.

So, the first step is to designate the RecyclerView height or to constraint it; from the constraints you want it to expand to the bottom; so use 0dp for that. But in order to make the minimum height to wrap content of the RecyclerView (in case that the items don't exceed the screen height); you can set the default height constraint to wrap with app:layout_constraintHeight_default="wrap" constraint.

Then remove app:layout_constraintBottom_toTopOf="@+id/exploreList" from the HorizontalScrollView, this actually made the bottom item of the RV hide (your main issue); because it is an over-constraint; the HorizontalScrollView tends to push the RV to the bottom while the RV tends to push the HorizontalScrollView to the top.

This will solve the main issue; but when the items are fully accommodated by the screen (no scrolling in the RV), then it will be biased in the middle; to fix this use the bias with app:layout_constraintVertical_bias="0.0" to be biased to the top.

Adding this in place into the layout:

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <androidx.appcompat.widget.SearchView
        android:id="@+id/searchView"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginStart="10dp"
        android:layout_marginTop="10dp"
        android:layout_marginEnd="16dp"
        app:closeIcon="@drawable/ic_cancel"
        app:layout_constraintBottom_toTopOf="@+id/exploreScroll"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent"
        app:layout_constraintVertical_bias="0.0"
        app:layout_constraintVertical_chainStyle="packed" />

    <HorizontalScrollView
        android:id="@+id/exploreScroll"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_marginStart="10dp"
        android:layout_marginTop="10dp"
        android:scrollbars="none"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toBottomOf="@+id/searchView">

        <com.google.android.material.chip.ChipGroup
            android:id="@+id/exploreChips"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            app:chipSpacingHorizontal="10dp"
            app:layout_constraintLeft_toLeftOf="parent"
            app:layout_constraintTop_toTopOf="parent"
            app:singleLine="true"
            app:singleSelection="true" />

    </HorizontalScrollView>

    <androidx.recyclerview.widget.RecyclerView
        android:id="@+id/exploreList"
        android:layout_width="match_parent"
        android:layout_height="0dp"
        android:layout_marginBottom="20dp"
        android:paddingTop="10dp"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintHeight_default="wrap"
        app:layout_constraintVertical_bias="0.0"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toBottomOf="@+id/exploreScroll" />

</androidx.constraintlayout.widget.ConstraintLayout>
