Percent stacked barchart: from Excel to ggplot2 in R

Question

My question is pretty simple. I'm trying to create a percent stacked barchart in ggplot2. I know exactly how I want it to be like because I created the same chart in Excel already, but I don't know how to obtain the same graph in R.

My issue is that the "fill" in my code corresponds to two sets of data: my x axis are nest box numbers, my y axis is a percentage (0%-100%), and the filling should be divided into males and females (e.g., in nest box number 5(b) there were 3 parasites, 2 females and 1 male, so the column should be divided into 67% FF and 33% MM).

This is my dataset:

> dput(broods_2020)
structure(list(`Age.(days)` = c("7-10 days", "15-20 days", "5-7
days",
"5-7 days", "5-7 days", "15-20 days", "6-8 days", "5-7 days",
"13-15 days", "10-12 days", "7-10 days", "8-10 days", "5-7 days",
"8-10 days", "20-25 days", "7-10 days", "8-10 days", "10-12 days",
"15-20 days", "15-20 days", "10-12 days", "12-15 days"), `Nest-
box.number.(x.brood)` = c(" 5 (a)",
"5 (b)", "7", "10", "11 (a)", "12", "27", "31", "37 (a)", "40",
"41", "200", "202", "205", "1 west", "5 west", "A3", "B7", "B8",
"B11", "C18", "C21"), `N.(Carnus)` = c(4, 3, 13, 36, 10, 8, 8,
17, 6, 3, 13, 8, 8, 9, 5, 10, 22, 28, 8, 8, 1, 3), MM = c(2,
1, 5, 13, 5, 3, 2, 8, 2, 2, 5, 4, 3, 4, 3, 5, 10, 9, 1, 3, 1,
1), FF = c(2, 2, 8, 23, 5, 5, 6, 9, 4, 1, 8, 4, 5, 5, 2, 5, 12,
19, 7, 5, 0, 2)), row.names = c(NA, 22L), class = "data.frame")

This is my code:

ggplot(broods_2020, aes(x=broods_2020$"Nest-box.number.(x.brood)",y=broods_2020$"MM",broods_2020$"FF",fill=broods_2020$"N.(Carnus)",)) + geom_col() +
  geom_bar(position="fill", stat="identity") +
  geom_bar(fill="#290DFB","#FF0000") +
  scale_y_continuous(labels = scales::percent_format(accuracy = 1))
+
  xlab("Nest box") + ylab("Collected Carnus hemapterus (%)") +
  ggtitle("2020 - PARASITE SEX RATIO (per brood)") +
  theme(axis.line.x = element_line(colour = 'black', size=0.5,
linetype='solid'),
        axis.line.y = element_line(colour = 'black', size=0.5,
linetype='solid')) +
  theme(title = element_text(face="plain", size = 12)) +
  theme(plot.title = element_text(hjust = 0.5, vjust =2)) +
  theme(axis.text.x = element_text(angle = 45, hjust=1)) +
  theme(panel.background = element_blank())

Is there an issue in my dataset? How do I create this chart?

Please do not post an image of code/data/errors [for these reasons](https://meta.stackoverflow.com/questions/285551/why-not-upload-images-of-code-errors-when-asking-a-question/285557#285557). Just include the code, console output, or data directly. If you want to post your data type `dput(NAME_OF_DATASET)` into the console and copy the output starting with `structure(....` into your post. Also it's good practice to try to provide [a minimal reproducible example](https://stackoverflow.com/questions/5963269/how-to-make-a-great-r-reproducible-example) including the code you have tried. — stefan, Nov 21 '22 at 10:33

score 0 · Accepted Answer · answered Nov 21 '22 at 11:14

Is this closer to what you're looking for?

If involves a few steps:

pivot_wider puts sex as one variable and n as another - this is what allows you to set a colour to represent each sex
n is passed as the y value to aes and sex as the fill value
geom_col(position = "fill") then fills the bar up to 100% for each x value (Nest-box.number.(x.brood))
You only need one geom_ layer for this - geom_bars are not needed
Setting the fill colours to match MM and FF is done in scale_fill_manual(values = ...)

library(ggplot2)
library(tidyr)


broods_2020 |>
  pivot_longer(c(MM, FF), names_to = "sex", values_to = "n") |>
  ggplot(aes(x = `Nest-box.number.(x.brood)`, y = n, fill = sex)) +
  geom_col(position = "fill") +
  scale_fill_manual("Sex", values = c("MM" = "#290DFB", "FF" = "#FF0000")) +
  scale_y_continuous("Percent", labels = scales::percent_format(accuracy = 1)) +
  xlab("Nest box") + ylab("Collected Carnus hemapterus (%)") +
  ggtitle("2020 - PARASITE SEX RATIO (per brood)") +
  theme(
    axis.line.x = element_line(
      colour = 'black',
      size = 0.5,
      linetype = 'solid'
    ),
    axis.line.y = element_line(
      colour = 'black',
      size = 0.5,
      linetype = 'solid'
    )
  ) +
  theme(title = element_text(face = "plain", size = 12)) +
  theme(plot.title = element_text(hjust = 0.5, vjust = 2)) +
  theme(axis.text.x = element_text(angle = 45, hjust = 1)) +
  theme(panel.background = element_blank())
