Create a UIScrollView that grows to a certain point, then becomes scrollable

Question

The problem

I want to create something like the UISheetPresentationController with detents, but that fits its content and grows in height as content is added, up to the height of the screen. Once it has grown to the height of the screen, I want it to then stop growing and scroll. I want to achieve all of this with autolayout.

So you'd have:

- ContainerView that takes the width and height of the screen
  | - DraggableModalView
    | - UIScrollView
      | - ContentView
        | - List content

Example 1: I have just 1 list item that has a height of 50.0 pixels, then the Draggable modal view will also only be 50.0 pixels in height.

Example 2: I have 100 list items, each with a height of 50.0 pixels. The Draggable modal view will be the height of the screen, showing only the first handful of list items, and the content can be scrolled.

I should also be able to drag the modal away.

What I've tried so far:

ContainerView constraints

• Pin bottom, leading, trailing, top to view controller

DraggableModalView constraints:

• Pin bottom, leading, trailing top ContainerView
• Pin >= topAnchor of container to stop it growing

UIScrollView constraints

• Pin bottom, leading, trailing, top to DraggableModalView

ContentView constraints

• Pin bottom, leading, trailing, top to UIScrollView
• Pin width to equal DraggableModalView
• Pin height to DraggableModalView (this is what makes the UIScrollView grow) but set a low priority so this breaks when it hits the top.

List items

• Added to a stack view pinned to the ContentView

Answer 1

You can make a scroll view "grow until you reach the top, then scroll" by constraining its frame to its content.

Yes, that sounds a little odd, and is not what we generally think of when it comes to scroll views.

Assuming we've added a stack view to a "content" view, and added that content view to the scroll view, common constraints look like this:

// scroll view constrained to all 4 sides of the view
//  with 20-points "padding"
scrollView.topAnchor.constraint(equalTo: view.topAnchor, constant: 20.0),
scrollView.leadingAnchor.constraint(equalTo: view.leadingAnchor, constant: 20.0),
scrollView.trailingAnchor.constraint(equalTo: view.trailingAnchor, constant: -20.0),
scrollView.bottomAnchor.constraint(equalTo: view.bottomAnchor, constant: -20.0),

// content view constrained to all 4 sides of the scroll view's Content Layout Guide
//  with 8-points "padding"
contentView.topAnchor.constraint(equalTo: scrollView.contentLayoutGuide.topAnchor, constant: 8.0),
contentView.leadingAnchor.constraint(equalTo: scrollView.contentLayoutGuide.leadingAnchor, constant: 8.0),
contentView.trailingAnchor.constraint(equalTo: scrollView.contentLayoutGuide.trailingAnchor, constant: -8.0),
contentView.bottomAnchor.constraint(equalTo: scrollView.contentLayoutGuide.bottomAnchor, constant: -8.0),

contentView.widthAnchor.constraint(equalTo: scrollView.frameLayoutGuide.widthAnchor, constant: -16.0),

// stack view constrained to all 4 sides of the content view
//  with 8-points "padding"
stackView.topAnchor.constraint(equalTo: contentView.topAnchor, constant: 8.0),
stackView.leadingAnchor.constraint(equalTo: contentView.leadingAnchor, constant: 8.0),
stackView.trailingAnchor.constraint(equalTo: contentView.trailingAnchor, constant: -8.0),
stackView.bottomAnchor.constraint(equalTo: contentView.bottomAnchor, constant: -8.0),


We can change the .topAnchor to:

scrollView.topAnchor.constraint(greaterThanOrEqualTo: view.topAnchor, constant: 20.0),

and add a height constraint -- with less-than-required priority:

// this will grow/shrink the scrollView height
//  to match the contentView height (plus 16-points for the top/bottom "padding")
let svHeight = scrollView.heightAnchor.constraint(equalTo: contentView.heightAnchor, constant: 16.0)

// less-than-required priority, so we can set a max-height (or max-top)
svHeight.priority = .defaultHigh

// activate it
svHeight.isActive = true


Now, as the contentView height changes - such as adding/removing labels to the stack view - the scroll view's height will change accordingly... until it reaches its "max-height / max-top" constraint.

Here's a quick example:

class SimpleSelfSizingScrollViewVC: UIViewController {

    let scrollView = UIScrollView()
    let contentView = UIView()
    let stackView = UIStackView()

    let maxHeightLabel = UILabel()

    override func viewDidLoad() {
        super.viewDidLoad()

        var config = UIButton.Configuration.filled()

        config.title = "Add"

        let btnA = UIButton(configuration: config)
        btnA.addAction (
            UIAction { _ in
                let v = UILabel()
                v.textAlignment = .center
                v.text = "Label \(self.stackView.arrangedSubviews.count + 1)"
                v.backgroundColor = .yellow
                v.heightAnchor.constraint(equalToConstant: 50.0).isActive = true
                self.stackView.addArrangedSubview(v)
            }, for: .touchUpInside
        )

        config.title = "Remove"

        let btnB = UIButton(configuration: config)
        btnB.addAction (
            UIAction { _ in
                if self.stackView.arrangedSubviews.count > 1 {
                    self.stackView.arrangedSubviews.last?.removeFromSuperview()
                }
            }, for: .touchUpInside
        )

        let btnStack = UIStackView(arrangedSubviews: [btnA, btnB])
        btnStack.spacing = 20
        btnStack.distribution = .fillEqually

        [btnStack, maxHeightLabel, scrollView, contentView, stackView].forEach { v in
            v.translatesAutoresizingMaskIntoConstraints = false
        }

        contentView.addSubview(stackView)
        scrollView.addSubview(contentView)

        view.addSubview(btnStack)
        view.addSubview(maxHeightLabel)
        view.addSubview(scrollView)

        let g = view.safeAreaLayoutGuide
        let cg = scrollView.contentLayoutGuide
        let fg = scrollView.frameLayoutGuide

        // this will grow/shrink the scrollView height
        //  to match the contentView height (plus 16-points for the top/bottom "padding")
        let svHeight = scrollView.heightAnchor.constraint(equalTo: contentView.heightAnchor, constant: 16.0)

        // less-than-required priority, so we can set a max-height (or max-top)
        svHeight.priority = .defaultHigh

        // activate it
        svHeight.isActive = true

        NSLayoutConstraint.activate([

            // add/remove buttons near the top
            btnStack.topAnchor.constraint(equalTo: g.topAnchor, constant: 40.0),
            btnStack.leadingAnchor.constraint(equalTo: g.leadingAnchor, constant: 20.0),
            btnStack.trailingAnchor.constraint(equalTo: g.trailingAnchor, constant: -20.0),

            // this will determine the bottom and max-height / max-top of the scroll view
            maxHeightLabel.topAnchor.constraint(equalTo: btnStack.bottomAnchor, constant: 40.0),
            maxHeightLabel.leadingAnchor.constraint(equalTo: g.leadingAnchor, constant: 40.0),
            maxHeightLabel.widthAnchor.constraint(equalToConstant: 80.0),
            maxHeightLabel.bottomAnchor.constraint(equalTo: g.bottomAnchor, constant: -80.0),

            // scroll view TOP is greaterThanOrEqualTo the maxHeightLable TOP
            scrollView.topAnchor.constraint(greaterThanOrEqualTo: maxHeightLabel.topAnchor),

            scrollView.leadingAnchor.constraint(equalTo: maxHeightLabel.trailingAnchor, constant: 20.0),
            scrollView.trailingAnchor.constraint(equalTo: g.trailingAnchor, constant: -40.0),
            scrollView.bottomAnchor.constraint(equalTo: maxHeightLabel.bottomAnchor, constant: 0.0),

            // content view constrained to all 4 sides of the scroll view's Content Layout Guide
            //  with 8-points "padding"
            contentView.topAnchor.constraint(equalTo: cg.topAnchor, constant: 8.0),
            contentView.leadingAnchor.constraint(equalTo: cg.leadingAnchor, constant: 8.0),
            contentView.trailingAnchor.constraint(equalTo: cg.trailingAnchor, constant: -8.0),
            contentView.bottomAnchor.constraint(equalTo: cg.bottomAnchor, constant: -8.0),

            contentView.widthAnchor.constraint(equalTo: fg.widthAnchor, constant: -16.0),

            // stack view constrained to all 4 sides of the content view
            //  with 8-points "padding"
            stackView.topAnchor.constraint(equalTo: contentView.topAnchor, constant: 8.0),
            stackView.leadingAnchor.constraint(equalTo: contentView.leadingAnchor, constant: 8.0),
            stackView.trailingAnchor.constraint(equalTo: contentView.trailingAnchor, constant: -8.0),
            stackView.bottomAnchor.constraint(equalTo: contentView.bottomAnchor, constant: -8.0),

        ])

        maxHeightLabel.textAlignment = .center
        maxHeightLabel.numberOfLines = 0
        maxHeightLabel.font = .systemFont(ofSize: 14.0, weight: .regular)
        maxHeightLabel.backgroundColor = .systemYellow

        stackView.axis = .vertical
        stackView.spacing = 20

        // start with 3 labels in the scroll view
        for _ in 1...3 {
            let v = UILabel()
            v.textAlignment = .center
            v.text = "Label \(self.stackView.arrangedSubviews.count + 1)"
            v.backgroundColor = .yellow
            v.heightAnchor.constraint(equalToConstant: 50.0).isActive = true
            stackView.addArrangedSubview(v)
        }

        view.backgroundColor = UIColor(white: 0.95, alpha: 1.0)

        // so we can see the framing
        scrollView.backgroundColor = .systemRed
        contentView.backgroundColor = .systemBlue
        stackView.backgroundColor = .systemGreen

        scrollView.layer.borderColor = UIColor.blue.cgColor
        scrollView.layer.borderWidth = 2

    }

    override func viewDidLayoutSubviews() {
        super.viewDidLayoutSubviews()
        maxHeightLabel.text = String(format: "Max\nHeight:\n\n%0.2f", maxHeightLabel.frame.height)
    }

}

It starts out looking like this (we're beginning with 3 labels in the stack view):

• The yellow label on the left is what we'll use to control the scroll view's bottom and "max-height / max-top."
• The scroll view has a red background and a black border.
• The "content" view has a blue background
• the stack view has a green background
• and the stack view's arranged subviews have yellow backgrounds

Tap the Add button:

we add a label and the scroll view grows in height.

Tap again:

and we add another label and the scroll view grows in height.

After 8 or 9 labels (depending on device height):

and the scroll view stops growing and its content becomes scrollable.
