How to set display resolution via PowerShell on Win10 Pro

Question

I was asked by a client's IT admin to "write a powershell script that sets the resolution manually on bootup". Presumably it is possible if they're asking me to do this. I have absolutely no experience with powershell. My scripts/commands and their errors are as follows:

Set-DisplayResolution -Width 1024 -Height 768

Set-DisplayResolution is not recognized as the name of a cmdlet, function, script file, or operable program.

Set-ScreenResolution -Width 1024 -Height 768

Set-ScreenResolution is not recognized as the name of a cmdlet, function, script file, or operable program.

SetDisplayResolution -Width 1024 -Height 768

SetDisplayResolution is not recognized as the name of a cmdlet, function, script file, or operable program.

What am I missing? Thank you.

score 16 · Answer 1 · edited Jan 21 '23 at 19:46

16

You need to install the DisplaySettings module from Powershell-Gallery to get this function.

Module Installation

Install-Module -Name DisplaySettings

Usage

Set-DisplayResolution -Width 800 -Height 600

edited Jan 21 '23 at 19:46

Guilherme Silva Sousa

781

answered Apr 26 '22 at 09:25

Yechiel Worenklein

191

Albin · Accepted Answer · 2019-10-17T17:42:30.303

Not sure where you got your example from but in a native powershell there is no command to set the resolution.

I use AutoHotKey. You can build your own script there or use an example from the net.

Or you could write your own function, that can be called from powershell: see here

And of course there are several 3rd party tools depending on your requirements. Here's one example that works with a script as well or here are 7 others. What exactly are you trying to do?

score 3 · Answer 3 · answered Jul 09 '21 at 16:53

Per Albin's answer:

Make a setResolution.ps1 file with the following contents (src):

Function Set-ScreenResolution {
<#
    .Synopsis
        Sets the Screen Resolution of the primary monitor
    .Description
        Uses Pinvoke and ChangeDisplaySettings Win32API to make the change
    .Example
        Set-ScreenResolution -Width 1024 -Height 768

    #>
param (
[Parameter(Mandatory=$true,
           Position = 0)]
[int]
$Width,
[Parameter(Mandatory=$true,
           Position = 1)]
[int]
$Height
)
$pinvokeCode = @"
using System;
using System.Runtime.InteropServices;
namespace Resolution
{
[StructLayout(LayoutKind.Sequential)]
public struct DEVMODE1
{
    [MarshalAs(UnmanagedType.ByValTStr, SizeConst = 32)]
    public string dmDeviceName;
    public short dmSpecVersion;
    public short dmDriverVersion;
    public short dmSize;
    public short dmDriverExtra;
    public int dmFields;

    public short dmOrientation;
    public short dmPaperSize;
    public short dmPaperLength;
    public short dmPaperWidth;

    public short dmScale;
    public short dmCopies;
    public short dmDefaultSource;
    public short dmPrintQuality;
    public short dmColor;
    public short dmDuplex;
    public short dmYResolution;
    public short dmTTOption;
    public short dmCollate;
    [MarshalAs(UnmanagedType.ByValTStr, SizeConst = 32)]
    public string dmFormName;
    public short dmLogPixels;
    public short dmBitsPerPel;
    public int dmPelsWidth;
    public int dmPelsHeight;

    public int dmDisplayFlags;
    public int dmDisplayFrequency;

    public int dmICMMethod;
    public int dmICMIntent;
    public int dmMediaType;
    public int dmDitherType;
    public int dmReserved1;
    public int dmReserved2;

    public int dmPanningWidth;
    public int dmPanningHeight;
};



class User_32
{
    [DllImport(&quot;user32.dll&quot;)]
    public static extern int EnumDisplaySettings(string deviceName, int modeNum, ref DEVMODE1 devMode);
    [DllImport(&quot;user32.dll&quot;)]
    public static extern int ChangeDisplaySettings(ref DEVMODE1 devMode, int flags);

    public const int ENUM_CURRENT_SETTINGS = -1;
    public const int CDS_UPDATEREGISTRY = 0x01;
    public const int CDS_TEST = 0x02;
    public const int DISP_CHANGE_SUCCESSFUL = 0;
    public const int DISP_CHANGE_RESTART = 1;
    public const int DISP_CHANGE_FAILED = -1;
}



public class PrmaryScreenResolution
{
    static public string ChangeResolution(int width, int height)
    {

        DEVMODE1 dm = GetDevMode1();

        if (0 != User_32.EnumDisplaySettings(null, User_32.ENUM_CURRENT_SETTINGS, ref dm))
        {

            dm.dmPelsWidth = width;
            dm.dmPelsHeight = height;

            int iRet = User_32.ChangeDisplaySettings(ref dm, User_32.CDS_TEST);

            if (iRet == User_32.DISP_CHANGE_FAILED)
            {
                return &quot;Unable To Process Your Request. Sorry For This Inconvenience.&quot;;
            }
            else
            {
                iRet = User_32.ChangeDisplaySettings(ref dm, User_32.CDS_UPDATEREGISTRY);
                switch (iRet)
                {
                    case User_32.DISP_CHANGE_SUCCESSFUL:
                        {
                            return &quot;Success&quot;;
                        }
                    case User_32.DISP_CHANGE_RESTART:
                        {
                            return &quot;You Need To Reboot For The Change To Happen.\n If You Feel Any Problem After Rebooting Your Machine\nThen Try To Change Resolution In Safe Mode.&quot;;
                        }
                    default:
                        {
                            return &quot;Failed To Change The Resolution&quot;;
                        }
                }

            }


        }
        else
        {
            return &quot;Failed To Change The Resolution.&quot;;
        }
    }

    private static DEVMODE1 GetDevMode1()
    {
        DEVMODE1 dm = new DEVMODE1();
        dm.dmDeviceName = new String(new char[32]);
        dm.dmFormName = new String(new char[32]);
        dm.dmSize = (short)Marshal.SizeOf(dm);
        return dm;
    }
}

}
"@
Add-Type $pinvokeCode -ErrorAction SilentlyContinue
[Resolution.PrmaryScreenResolution]::ChangeResolution($width,$height)
}
Set-ScreenResolution -Width 1024 -Height 768

Then the file can be executed from powershell as follows

`C:\path-to-file\setResolution.ps1`

score 0 · Answer 4 · edited Feb 14 '22 at 13:04

The powershell script from Albin's post was working OK - but on one machine only let me set 1920x1080 and not 1920x1200 which I was able to do manually. In the end I had to use Nirsoft MultiMonitor which lets you save and load profiles. I was able to edit the config file and just put in the resolution parameters and it is working quite nicely. The config file looks like this :

Name=\\.\DISPLAY1
Width=1920
Height=1200

While I prefer to avoid third party tools where possible, on this occasion its free, lightweight and just works very well (and didn't complain about any virus)...
