Custom UITableViewCell from nib in Swift

Question

I'm trying to create a custom table view cell from a nib. I'm referring to this article here. I'm facing two issues.

I created a .xib file with a UITableViewCell object dragged on to it. I created a subclass of UITableViewCell and set it as the cell's class and Cell as the reusable identifier.

import UIKit

class CustomOneCell: UITableViewCell {

    @IBOutlet weak var middleLabel: UILabel!
    @IBOutlet weak var leftLabel: UILabel!
    @IBOutlet weak var rightLabel: UILabel!

    required init(coder aDecoder: NSCoder!) {
        super.init(coder: aDecoder)
    }

    override init(style: UITableViewCellStyle, reuseIdentifier: String!) {
        super.init(style: style, reuseIdentifier: reuseIdentifier)
    }

    override func awakeFromNib() {
        super.awakeFromNib()
        // Initialization code
    }

    override func setSelected(selected: Bool, animated: Bool) {
        super.setSelected(selected, animated: animated)

        // Configure the view for the selected state
    }

}

In the UITableViewController I have this code,

import UIKit

class ViewController: UITableViewController, UITableViewDataSource, UITableViewDelegate {

    var items = ["Item 1", "Item2", "Item3", "Item4"]

    override func viewDidLoad() {
        super.viewDidLoad()
    }

    // MARK: - UITableViewDataSource
    override func tableView(tableView: UITableView!, numberOfRowsInSection section: Int) -> Int {
        return items.count
    }

    override func tableView(tableView: UITableView!, cellForRowAtIndexPath indexPath: NSIndexPath!) -> UITableViewCell! {
        let identifier = "Cell"
        var cell: CustomOneCell! = tableView.dequeueReusableCellWithIdentifier(identifier) as? CustomOneCell
        if cell == nil {
            tableView.registerNib(UINib(nibName: "CustomCellOne", bundle: nil), forCellReuseIdentifier: identifier)
            cell = tableView.dequeueReusableCellWithIdentifier(identifier) as? CustomOneCell
        }

        return cell
    }
}

This code complies with no errors but when I run it in the simulator, it looks like this.

In the UITableViewController in the storyboard I haven't done anything to the cell. Blank identifier and no subclass. I tried adding the Cell identifier to the prototype cell and ran it again but I get the same result.

Another error I faced is, when I tried to implement the following method in the UITableViewController.

override func tableView(tableView: UITableView!, willDisplayCell cell: CustomOneCell!, forRowAtIndexPath indexPath: NSIndexPath!) {

    cell.middleLabel.text = items[indexPath.row]
    cell.leftLabel.text = items[indexPath.row]
    cell.rightLabel.text = items[indexPath.row]
}

As shown in the article I mentioned I changed the cell parameter's type form UITableViewCell to CustomOneCell which is my subclass of UITableViewCell. But I get the following error,

Overriding method with selector 'tableView:willDisplayCell:forRowAtIndexPath:' has incompatible type '(UITableView!, CustomOneCell!, NSIndexPath!) -> ()'

Anyone have any idea how to resolve these errors? These seemed to work fine in Objective-C.

Thank you.

EDIT: I just noticed if I change the simulator's orientation to landscape and turn it back to portrait, the cells appear! I still couldn't figure out what's going on. I uploaded an Xcode project here demonstrating the problem if you have time for a quick look.

Answer 1

With Swift 5 and iOS 12.2, you should try the following code in order to solve your problem:

CustomCell.swift

import UIKit

class CustomCell: UITableViewCell {

    // Link those IBOutlets with the UILabels in your .XIB file
    @IBOutlet weak var middleLabel: UILabel!
    @IBOutlet weak var leftLabel: UILabel!
    @IBOutlet weak var rightLabel: UILabel!

}

TableViewController.swift

import UIKit

class TableViewController: UITableViewController {

    let items = ["Item 1", "Item2", "Item3", "Item4"]

    override func viewDidLoad() {
        super.viewDidLoad()
        tableView.register(UINib(nibName: "CustomCell", bundle: nil), forCellReuseIdentifier: "CustomCell")
    }

    // MARK: - UITableViewDataSource

    override func tableView(_ tableView: UITableView, numberOfRowsInSection section: Int) -> Int {
        return items.count
    }

    override func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath) -> UITableViewCell {
        let cell = tableView.dequeueReusableCell(withIdentifier: "CustomCell", for: indexPath) as! CustomCell

        cell.middleLabel.text = items[indexPath.row]
        cell.leftLabel.text = items[indexPath.row]
        cell.rightLabel.text = items[indexPath.row]

        return cell
    }

}

---

The image below shows a set of constraints that work with the provided code without any constraints ambiguity message from Xcode:

Answer 2

Here's my approach using Swift 2 and Xcode 7.3. This example will use a single ViewController to load two .xib files -- one for a UITableView and one for the UITableCellView.

For this example you can drop a UITableView right into an empty TableNib.xib file. Inside, set the file's owner to your ViewController class and use an outlet to reference the tableView.

and

Now, in your view controller, you can delegate the tableView as you normally would, like so

class ViewController: UIViewController, UITableViewDelegate, UITableViewDataSource {

    @IBOutlet weak var tableView: UITableView!

    ...

    override func viewDidLoad() {
        super.viewDidLoad()
        // Do any additional setup after loading the view, typically from a nib.

        // Table view delegate
        self.tableView.delegate = self
        self.tableView.dataSource = self

        ...

To create your Custom cell, again, drop a Table View Cell object into an empty TableCellNib.xib file. This time, in the cell .xib file you don't have to specify an "owner" but you do need to specify a Custom Class and an identifier like "TableCellId"

Create your subclass with whatever outlets you need like so

class TableCell: UITableViewCell {

    @IBOutlet weak var nameLabel: UILabel!

}

Finally... back in your View Controller, you can load and display the entire thing like so

override func viewDidLoad() {
    super.viewDidLoad()
    // Do any additional setup after loading the view, typically from a nib.

    // First load table nib
    let bundle = NSBundle(forClass: self.dynamicType)
    let tableNib = UINib(nibName: "TableNib", bundle: bundle)
    let tableNibView = tableNib.instantiateWithOwner(self, options: nil)[0] as! UIView

    // Then delegate the TableView
    self.tableView.delegate = self
    self.tableView.dataSource = self

    // Set resizable table bounds
    self.tableView.frame = self.view.bounds
    self.tableView.autoresizingMask = [.FlexibleWidth, .FlexibleHeight]

    // Register table cell class from nib
    let cellNib = UINib(nibName: "TableCellNib", bundle: bundle)
    self.tableView.registerNib(cellNib, forCellReuseIdentifier: self.tableCellId)

    // Display table with custom cells
    self.view.addSubview(tableNibView)

}

The code shows how you can simply load and display a nib file (the table), and second how to register a nib for cell use.

Hope this helps!!!

Answer 3

Swift 4

Register Nib

override func viewDidLoad() {
    super.viewDidLoad()
    tblMissions.register(UINib(nibName: "MissionCell", bundle: nil), forCellReuseIdentifier: "MissionCell")
}

In TableView DataSource

func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath) -> UITableViewCell {
    guard let cell = tableView.dequeueReusableCell(withIdentifier: "MissionCell", for: indexPath) as? MissionCell else { return UITableViewCell() }
    return cell
}

Answer 4

Detailed Solution with Screenshots

1. Create an empty user interface file and name it MyCustomCell.xib.

2. Add a UITableViewCell as the root of your xib file and any other visual components you want.

3. Create a cocoa touch class file with class name MyCustomCell as a subclass of UITableViewCell.

4. Set the custom class and reuse identifier for your custom table view cell.

5. Open the assistant editor and ctrl+drag to create outlets for your visual components.

6. Configure a UIViewController to use your custom cell.

class MyViewController: UIViewController {

    @IBOutlet weak var myTable: UITableView!

    override func viewDidLoad {
        super.viewDidLoad()

        let nib = UINib(nibName: "MyCustomCell", bundle: nil)
        myTable.register(nib, forCellReuseIdentifier: "MyCustomCell")
        myTable.dataSource = self
    }

    func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath) -> UITableViewCell {
        if let cell = tableView.dequeueReusableCell(withIdentifier: "MyCustomCell") as? MyCustomCell {
            cell.myLabel.text = "Hello world."
            return cell
        }
        ...
    }
}

Answer 5

swift 4.1.2

xib.

Create ImageCell2.swift

Step 1

import UIKit

class ImageCell2: UITableViewCell {

    @IBOutlet weak var imgBookLogo: UIImageView!
    @IBOutlet weak var lblTitle: UILabel!
    @IBOutlet weak var lblPublisher: UILabel!
    override func awakeFromNib() {
        super.awakeFromNib()
        // Initialization code
    }

    override func setSelected(_ selected: Bool, animated: Bool) {
        super.setSelected(selected, animated: animated)
    }

}

step 2 . According Viewcontroller class

  import UIKit

    class ImageListVC: UIViewController,UITableViewDataSource,UITableViewDelegate {
    @IBOutlet weak var tblMainVC: UITableView!

    var arrBook : [BookItem] = [BookItem]()

    override func viewDidLoad() {
        super.viewDidLoad()
         //Regester Cell
        self.tblMainVC.register(UINib.init(nibName: "ImageCell2", bundle: nil), forCellReuseIdentifier: "ImageCell2")
        // Response Call adn Disply Record
        APIManagerData._APIManagerInstance.getAPIBook { (itemInstance) in
            self.arrBook = itemInstance.arrItem!
            self.tblMainVC.reloadData()
        }
    }
    //MARK: DataSource & delegate
    func tableView(_ tableView: UITableView, numberOfRowsInSection section: Int) -> Int {
        return self.arrBook.count
    }
    func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath) -> UITableViewCell {
//    [enter image description here][2]
        let cell  = tableView.dequeueReusableCell(withIdentifier: "ImageCell2") as! ImageCell2
        cell.lblTitle.text = self.arrBook[indexPath.row].title
        cell.lblPublisher.text = self.arrBook[indexPath.row].publisher
        if let authors = self.arrBook[indexPath.row].author {
            for item in authors{
                print(" item \(item)")
            }
        }
        let  url  = self.arrBook[indexPath.row].imageURL
        if url == nil {
            cell.imgBookLogo.kf.setImage(with: URL.init(string: ""), placeholder: UIImage.init(named: "download.jpeg"))
        }
        else{
            cell.imgBookLogo.kf.setImage(with: URL(string: url!)!, placeholder: UIImage.init(named: "download.jpeg"))
        }
        return cell
    }
    func tableView(_ tableView: UITableView, heightForRowAt indexPath: IndexPath) -> CGFloat {
        return 90
    }

}

Answer 6

You did not register your nib as below:

tableView.registerNib(UINib(nibName: "CustomCell", bundle: nil), forCellReuseIdentifier: "CustomCell")

Answer 7

Another method that may work for you (it's how I do it) is registering a class.

Assume you create a custom tableView like the following:

class UICustomTableViewCell: UITableViewCell {...}

You can then register this cell in whatever UITableViewController you will be displaying it in with "registerClass":

override func viewDidLoad() {
    super.viewDidLoad()
    tableView.registerClass(UICustomTableViewCell.self, forCellReuseIdentifier: "UICustomTableViewCellIdentifier")
}

And you can call it as you would expect in the cell for row method:

override func tableView(tableView: UITableView, cellForRowAtIndexPath indexPath: NSIndexPath) -> UITableViewCell {
    let cell = tableView.dequeueReusableCellWithIdentifier("UICustomTableViewCellIdentifier", forIndexPath: indexPath) as! UICustomTableViewCell
    return cell
}

Answer 8

For fix the "Overriding method... has incompatible type..." error I've changed the function declaration to

override func tableView(tableView: (UITableView!),
                        cellForRowAtIndexPath indexPath: (NSIndexPath!))
    -> UITableViewCell {...}

(was -> UITableViewCell! -- with exclamation mark at the end)

Answer 9

I had to make sure that when creating the outlet to specify that I was hooking to the cell, not the object's owner. When the menu appears to name it you have to select it in the 'object' dropdown menu. Of course you must declare the cell as your class too, not just 'TableViewCellClass'. Otherwise I would keep getting the class not key compliant.

Answer 10

This line add in TableView cell:

static var nib  : UINib{
    return UINib(nibName: identifier, bundle: nil)
}

static var identifier : String{
    return String(describing: self)
}



And register in viewcontroller like

This line use in viewDidLoad

tableview.register(TopDealLikedTableViewCell.nib, forCellReuseIdentifier: TopDealLikedTableViewCell.identifier)

cell for row at indexpath

if let cell = tableView.dequeueReusableCell(withIdentifier:
    TopDealLikedTableViewCell.identifier) as? TopDealLikedTableViewCell{
    return cell
}

return UITableViewCell()

Answer 11

Simple take a xib with class UITableViewCell. Set the UI as per reuirement and assign IBOutlet. Use it in cellForRowAt() of table view like this:

//MARK: - table method

func tableView(_ tableView: UITableView, numberOfRowsInSection section: Int) -> Int {
    return self.arrayFruit.count
}
func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath) -> UITableViewCell {
    var cell:simpleTableViewCell? = tableView.dequeueReusableCell(withIdentifier:"simpleTableViewCell") as? simpleTableViewCell
    if cell == nil{
        tableView.register(UINib.init(nibName: "simpleTableViewCell", bundle: nil), forCellReuseIdentifier: "simpleTableViewCell")
        let arrNib:Array = Bundle.main.loadNibNamed("simpleTableViewCell",owner: self, options: nil)!
        cell = arrNib.first as? simpleTableViewCell
    }

    cell?.labelName.text = self.arrayFruit[indexPath.row]
    cell?.imageViewFruit.image = UIImage (named: "fruit_img")

    return cell!

}
func tableView(_ tableView: UITableView, heightForRowAt indexPath: IndexPath) -> CGFloat
{
 return 100.0
}

100% working without any issue (Tested)

Answer 12

Set on cell

static var identifier : String {
    return String(describing: self)
}

static var nib : UINib {
    return UINib(nibName: identifier, bundle: nil)
}
