Android relative layout problem with gravity

Question

How can i put textview with id="naslov" to the center? I also tried with layout_gravity="center" but that doesn't work either.

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="fill_parent"
android:layout_height="fill_parent">

<TextView
    android:id="@+id/naslov"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:textSize="20dip"
    android:text="Povzetek"
    android:gravity="center"/>
   <TextView
    android:id="@+id/aha"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:textSize="10dip"
    android:text="Vseh oddaj:"
       android:layout_below="@id/naslov"/>
 </RelativeLayout>

possible duplicate of [Android and Layouts](http://stackoverflow.com/questions/2990882/android-and-layouts) — Kuba hasn't forgotten Monica, May 26 '15 at 18:54

score 56 · Accepted Answer · answered Jul 04 '12 at 11:27

56

 android:layout_centerHorizontal="true"

answered Jul 04 '12 at 11:27

Alex Volovoy · Answer 2 · 2010-05-10T16:42:13.187

46

 android:layout_centerHorizontal="true"

there is also

android:layout_centerInParent="true"

Full list for RelativeLayout attributes is here

Also you can tell your TextView to fill_parent and then set gravity=center on it. So it'll center actual text within textView.

edited May 10 '10 at 16:42

answered May 10 '10 at 16:35

Alex Volovoy

67,778
13
73
54

score 6 · Answer 3 · edited Jun 20 '20 at 09:12

Supplemental Answer

As a more general answer to this question, layout_gravity does not work with the subviews of a RelativeLayout. It is for use with a LinearLayout or FrameLayout. However, the subviews of a RelativeLayout can still use gravity as usual because this is just how a view arranges its own content.

See the comparison in the following image. The green and blue views are TextViews inside of a RelativeLayout.

The gravity works but layout_gravity doesn't. See my fuller answer for more details.

See also

score 0 · Answer 4 · answered Feb 21 '18 at 11:48

Relative Layout does not make use of layout_gravity, however you use gravity values in following ways : center, left , left|center , right|center , right, top, bottom.

<!-- below widget displaying text in left center -->
<TextView
           android:id="@+id/song_title"
           android:layout_width="match_parent"
           android:layout_height="match_parent"
           android:text="sample name text"
           android:gravity="left|center"
           android:textSize="15sp" />
