How to Apply Gradient to background view of iOS Swift App

Question

I'm trying to apply a gradient as the background color of a View (main view of a storyboard). The code runs, but nothing changes. I'm using xCode Beta 2 and Swift.

Here's the code:

class Colors {
  let colorTop = UIColor(red: 192.0/255.0, green: 38.0/255.0, blue: 42.0/255.0, alpha: 1.0)
  let colorBottom = UIColor(red: 35.0/255.0, green: 2.0/255.0, blue: 2.0/255.0, alpha: 1.0)

  let gl: CAGradientLayer

  init() {
    gl = CAGradientLayer()
    gl.colors = [ colorTop, colorBottom]
    gl.locations = [ 0.0, 1.0]
  }
}

then in the view controller:

  let colors = Colors()

  func refresh() {
        view.backgroundColor = UIColor.clearColor()
        var backgroundLayer = colors.gl
        backgroundLayer.frame = view.frame
        view.layer.insertSublayer(backgroundLayer, atIndex: 0)
      }
    }
  }

I published a component that makes it easy, you can use it using cocoa pods, I suggest it because it is very simple and you can set it through interface builder on XCode. See more https://github.com/heuristisk/hkGraddiant — Anderson Santos Gusmão, Aug 16 '17 at 01:29
You are using UIColor elements on CAGradientLayer's property colors, but you must use CGColor instead! — Rodrigo Fava, Sep 29 '21 at 20:49

Leo Dabus · Answer 1 · 2020-06-14T06:06:37.220

Xcode 11 • Swift 5.1

You can design your own Gradient View as follow:

@IBDesignable
public class Gradient: UIView {
    @IBInspectable var startColor:   UIColor = .black { didSet { updateColors() }}
    @IBInspectable var endColor:     UIColor = .white { didSet { updateColors() }}
    @IBInspectable var startLocation: Double =   0.05 { didSet { updateLocations() }}
    @IBInspectable var endLocation:   Double =   0.95 { didSet { updateLocations() }}
    @IBInspectable var horizontalMode:  Bool =  false { didSet { updatePoints() }}
    @IBInspectable var diagonalMode:    Bool =  false { didSet { updatePoints() }}

    override public class var layerClass: AnyClass { CAGradientLayer.self }

    var gradientLayer: CAGradientLayer { layer as! CAGradientLayer }

    func updatePoints() {
        if horizontalMode {
            gradientLayer.startPoint = diagonalMode ? .init(x: 1, y: 0) : .init(x: 0, y: 0.5)
            gradientLayer.endPoint   = diagonalMode ? .init(x: 0, y: 1) : .init(x: 1, y: 0.5)
        } else {
            gradientLayer.startPoint = diagonalMode ? .init(x: 0, y: 0) : .init(x: 0.5, y: 0)
            gradientLayer.endPoint   = diagonalMode ? .init(x: 1, y: 1) : .init(x: 0.5, y: 1)
        }
    }
    func updateLocations() {
        gradientLayer.locations = [startLocation as NSNumber, endLocation as NSNumber]
    }
    func updateColors() {
        gradientLayer.colors = [startColor.cgColor, endColor.cgColor]
    }
    override public func traitCollectionDidChange(_ previousTraitCollection: UITraitCollection?) {
        super.traitCollectionDidChange(previousTraitCollection)
        updatePoints()
        updateLocations()
        updateColors()
    }

}

Can you please explain this line: override class var layerClass: AnyClass { return CAGradientLayer.self } — Mostafa, Jul 21 '17 at 22:06
https://developer.apple.com/documentation/uikit/uiview/1622626-layerclass — Leo Dabus, Sep 10 '17 at 02:31
what is the maximum number of location/positions/gradientstops could be applicable ? it seems more than certain number, iOS not rendering the gradient. The page is empty — Arun Prasad, Jan 07 '20 at 11:25
This is a simple and nice way, good effort from you. Thank you, +1 — mAc, May 15 '20 at 12:41

score 175 · Accepted Answer · edited Mar 10 '17 at 08:14

175

The Colors you're providing to gradient must be of type CGColor. So set your array of CGColor to gl.colors.

The correct code is :

class Colors {
    var gl:CAGradientLayer!

    init() {
        let colorTop = UIColor(red: 192.0 / 255.0, green: 38.0 / 255.0, blue: 42.0 / 255.0, alpha: 1.0).cgColor
        let colorBottom = UIColor(red: 35.0 / 255.0, green: 2.0 / 255.0, blue: 2.0 / 255.0, alpha: 1.0).cgColor

        self.gl = CAGradientLayer()
        self.gl.colors = [colorTop, colorBottom]
        self.gl.locations = [0.0, 1.0]
    }
}

edited Mar 10 '17 at 08:14

Community

1
1

answered Jun 24 '14 at 07:39

Yatheesha

10,412
5
42
45

Almost works, but *ONLY* works for portrait. Right edge of screen is black. – justingordon Jun 24 '14 at 18:27
21

this was key: gl.frame = view.bounds; – justingordon Jun 24 '14 at 22:50
2

I'm getting this error `fatal error: array element cannot be bridged to Objective-C`, when assigning to `.colors` property. What may be wrong with this? – Tricertops Jul 20 '14 at 19:10
3

I've fixed it. It's a bug in Swift, just store the array in variable with explicit type `[AnyObject]` and **then** assign it to `.colors` property. – Tricertops Jul 20 '14 at 19:17
1

let c: Array = [colorTop, colorBottom] – JP_ Sep 09 '14 at 06:46
7

for swift 1.0 the syntax would be `let c: [AnyObject] = [colorTop, colorBottom]` – Chris Sep 23 '14 at 07:55
Also, the frame of the layer should be updated. Please see the 'layoutSubviews' section at the @Leo Dabus 's answer. – EmreSURK Feb 18 '20 at 12:08
Make sure you set gradientLayer.frame = view.bounds instead of gradientLayer.frame = view.frame. Also, if the gradientLayer is covering your button's image and label, then you want to use button.layer.insertSublayer(gradientLayer, below: button.imageView.layer) instead of button.layer.insertSublayer(gradientLayerr, at: 0 ) – PatPatchPatrick Jul 01 '20 at 19:33

score 119 · Answer 3 · edited Aug 29 '20 at 00:45

119

Just modifying the above mentioned answer.

func setGradientBackground() {
    let colorTop =  UIColor(red: 255.0/255.0, green: 149.0/255.0, blue: 0.0/255.0, alpha: 1.0).cgColor
    let colorBottom = UIColor(red: 255.0/255.0, green: 94.0/255.0, blue: 58.0/255.0, alpha: 1.0).cgColor

    let gradientLayer = CAGradientLayer()
    gradientLayer.colors = [colorTop, colorBottom]
    gradientLayer.locations = [0.0, 1.0]
    gradientLayer.frame = self.view.bounds

    self.view.layer.insertSublayer(gradientLayer, at:0)
}

Then call this method within viewWillAppear

override func viewWillAppear(_ animated: Bool) {
    setGradientBackground()
    super.viewWillAppear(animated)
}

edited Aug 29 '20 at 00:45

jvarela

3,744
1
22
43

answered Aug 04 '16 at 17:17

katwal-Dipak

3,523
2
23
23

1

This puts a layer over existing elements so I cannot see anything. Any suggestions? – JamesG Sep 01 '16 at 18:47
31

replace `self.view.layer.addSublayer(gradientLayer)` with `self.view.layer.insertSublayer(gradientLayer, at: 0)`, this will put the layer "below" all others – WMR Sep 21 '16 at 10:43
Is there a way to remove this gradient effect? Like a remove function? – Tyler Rutt Jun 22 '20 at 14:47
Just remove the inserted sublayer – Okhan Okbay Feb 04 '21 at 08:38
Is there a way to remove sublayers at certain layer. Like 0 – Tyler Rutt Apr 30 '21 at 19:30
@TylerRutt just give a name to your layer and then you can filter it regardless of its position – Leo Dabus Jun 18 '21 at 03:26
I add this to a subView like this `func setGradientBackground(_ aView: UIView)`, `aView.layer.insertSublayer(gradientLayer, at:0)`. But the gradient is not applied, any suggestions? – Zhou Haibo Jun 25 '21 at 09:24
1

I move it into `viewDidLayoutSubviews` then it works:) Maybe `insertSublayer` will change the uiview's bounds. – Zhou Haibo Jun 25 '21 at 10:36
Attention to the fact that CAGradientLayer property colors is a [Any]?, but the elements must be CGColor, not UIColor. I made this mistake several times, and then nothing happens. – Rodrigo Fava Sep 29 '21 at 20:44

score 98 · Answer 4 · edited Apr 03 '20 at 13:02

98

And if you need to change the direction of the gradient you have to use startPoint and endPoint.

let gradient: CAGradientLayer = CAGradientLayer()

gradient.colors = [UIColor.blue.cgColor, UIColor.red.cgColor]
gradient.locations = [0.0 , 1.0]
gradient.startPoint = CGPoint(x: 0.0, y: 1.0)
gradient.endPoint = CGPoint(x: 1.0, y: 1.0)
gradient.frame = CGRect(x: 0.0, y: 0.0, width: self.view.frame.size.width, height: self.view.frame.size.height)

self.view.layer.insertSublayer(gradient, at: 0)

edited Apr 03 '20 at 13:02

pojo

5,892
9
35
47

answered Jan 17 '15 at 21:39

gasho

1,926
1
16
20

6

One of the problems you may face with this is that when you add a sublayer it may sit over all your other items, labels, image, etc. To overcome this create another view that sits below everything and set its constraints to that of the container you want the gradient in. Then set the gradient to be applied to this view. Subviews will then be inserted into this layer and not sit over anything else. – Micah Montoya Dec 16 '16 at 17:54

ChikabuZ · Answer 5 · 2018-03-30T10:44:33.433

I have these extensions:

@IBDesignable class GradientView: UIView {
    @IBInspectable var firstColor: UIColor = UIColor.red
    @IBInspectable var secondColor: UIColor = UIColor.green

    @IBInspectable var vertical: Bool = true

    lazy var gradientLayer: CAGradientLayer = {
        let layer = CAGradientLayer()
        layer.colors = [firstColor.cgColor, secondColor.cgColor]
        layer.startPoint = CGPoint.zero
        return layer
    }()

    //MARK: -

    required init?(coder aDecoder: NSCoder) {
        super.init(coder: aDecoder)

        applyGradient()
    }

    override init(frame: CGRect) {
        super.init(frame: frame)

        applyGradient()
    }

    override func prepareForInterfaceBuilder() {
        super.prepareForInterfaceBuilder()
        applyGradient()
    }

    override func layoutSubviews() {
        super.layoutSubviews()
        updateGradientFrame()
    }

    //MARK: -

    func applyGradient() {
        updateGradientDirection()
        layer.sublayers = [gradientLayer]
    }

    func updateGradientFrame() {
        gradientLayer.frame = bounds
    }

    func updateGradientDirection() {
        gradientLayer.endPoint = vertical ? CGPoint(x: 0, y: 1) : CGPoint(x: 1, y: 0)
    }
}

@IBDesignable class ThreeColorsGradientView: UIView {
    @IBInspectable var firstColor: UIColor = UIColor.red
    @IBInspectable var secondColor: UIColor = UIColor.green
    @IBInspectable var thirdColor: UIColor = UIColor.blue

    @IBInspectable var vertical: Bool = true {
        didSet {
            updateGradientDirection()
        }
    }

    lazy var gradientLayer: CAGradientLayer = {
        let layer = CAGradientLayer()
        layer.colors = [firstColor.cgColor, secondColor.cgColor, thirdColor.cgColor]
        layer.startPoint = CGPoint.zero
        return layer
    }()

    //MARK: -

    required init?(coder aDecoder: NSCoder) {
        super.init(coder: aDecoder)

        applyGradient()
    }

    override init(frame: CGRect) {
        super.init(frame: frame)

        applyGradient()
    }

    override func prepareForInterfaceBuilder() {
        super.prepareForInterfaceBuilder()
        applyGradient()
    }

    override func layoutSubviews() {
        super.layoutSubviews()
        updateGradientFrame()
    }

    //MARK: -

    func applyGradient() {
        updateGradientDirection()
        layer.sublayers = [gradientLayer]
    }

    func updateGradientFrame() {
        gradientLayer.frame = bounds
    }

    func updateGradientDirection() {
        gradientLayer.endPoint = vertical ? CGPoint(x: 0, y: 1) : CGPoint(x: 1, y: 0)
    }
}

@IBDesignable class RadialGradientView: UIView {

    @IBInspectable var outsideColor: UIColor = UIColor.red
    @IBInspectable var insideColor: UIColor = UIColor.green

    override func awakeFromNib() {
        super.awakeFromNib()

        applyGradient()
    }

    func applyGradient() {
        let colors = [insideColor.cgColor, outsideColor.cgColor] as CFArray
        let endRadius = sqrt(pow(frame.width/2, 2) + pow(frame.height/2, 2))
        let center = CGPoint(x: bounds.size.width / 2, y: bounds.size.height / 2)
        let gradient = CGGradient(colorsSpace: nil, colors: colors, locations: nil)
        let context = UIGraphicsGetCurrentContext()

        context?.drawRadialGradient(gradient!, startCenter: center, startRadius: 0.0, endCenter: center, endRadius: endRadius, options: CGGradientDrawingOptions.drawsBeforeStartLocation)
    }

    override func draw(_ rect: CGRect) {
        super.draw(rect)

        #if TARGET_INTERFACE_BUILDER
            applyGradient()
        #endif
    }
}

Usage:

adding this to my VC view block everything. All the elements are hidden under the gradient. Whats the way around — Aakash Dave, Jan 24 '18 at 10:47
Changing the `self.layer.addSublayer(layer)` to `self.layer.insertSublayer(layer, at: 0)` seems to prevent the gradient from obfuscating everything in the interface builder (at least in my one test) — S.Walker, Mar 29 '18 at 23:55

score 24 · Answer 6 · edited Dec 25 '16 at 20:33

24

In Swift3 try this:

 func addGradient(){

    let gradient:CAGradientLayer = CAGradientLayer()
    gradient.frame.size = self.viewThatHoldsGradient.frame.size
    gradient.colors = [UIColor.white.cgColor,UIColor.white.withAlphaComponent(0).cgColor] //Or any colors
    self.viewThatHoldsGradient.layer.addSublayer(gradient)

}

edited Dec 25 '16 at 20:33

Himanshu A Jadav

2,286
22
34

answered Nov 29 '15 at 10:27

Mohammad Zaid Pathan

16,304
7
99
130

6

gradient.startPoint = CGPoint(x: 0.0, y: 1.0) gradient.endPoint = CGPoint(x: 1.0, y: 1.0) for different gradient position. – Pan Mluvčí Jun 04 '16 at 20:07
colorWithAlphaComponent has been renamed to withAlphaComponent – etayluz Dec 04 '16 at 09:31

score 22 · Answer 7 · answered Jan 27 '15 at 04:04

I made an UIView extension to apply a basic gradient to any view

extension UIView {
    func layerGradient() {
        let layer : CAGradientLayer = CAGradientLayer()
        layer.frame.size = self.frame.size
        layer.frame.origin = CGPointMake(0.0,0.0)
        layer.cornerRadius = CGFloat(frame.width / 20)

        let color0 = UIColor(red:250.0/255, green:250.0/255, blue:250.0/255, alpha:0.5).CGColor
        let color1 = UIColor(red:200.0/255, green:200.0/255, blue: 200.0/255, alpha:0.1).CGColor
        let color2 = UIColor(red:150.0/255, green:150.0/255, blue: 150.0/255, alpha:0.1).CGColor
        let color3 = UIColor(red:100.0/255, green:100.0/255, blue: 100.0/255, alpha:0.1).CGColor
        let color4 = UIColor(red:50.0/255, green:50.0/255, blue:50.0/255, alpha:0.1).CGColor
        let color5 = UIColor(red:0.0/255, green:0.0/255, blue:0.0/255, alpha:0.1).CGColor
        let color6 = UIColor(red:150.0/255, green:150.0/255, blue:150.0/255, alpha:0.1).CGColor

        layer.colors = [color0,color1,color2,color3,color4,color5,color6]
        self.layer.insertSublayer(layer, atIndex: 0)
    }
}

I might be misunderstanding but it might be better to let the user pass the array of colors to that functions rather than hard coding them in it (unless you always want to apply the same gradient). — , Aug 14 '15 at 12:25
`CGPointMake(0.0,0.0)` can be replaced with `CGPointZero` for brevity — JSmyth, Apr 10 '16 at 10:27

Jaywant Khedkar · Answer 8 · 2018-08-31T09:47:02.680

18

Try This , It's working for me,

  var gradientView = UIView(frame: CGRect(x: 0, y: 0, width: 320, height: 35))
  let gradientLayer:CAGradientLayer = CAGradientLayer()
  gradientLayer.frame.size = self.gradientView.frame.size
  gradientLayer.colors =
  [UIColor.white.cgColor,UIColor.red.withAlphaComponent(1).cgColor]
  //Use diffrent colors
  gradientView.layer.addSublayer(gradientLayer)

You can add starting and end point of gradient color.

    gradientLayer.startPoint = CGPoint(x: 0.0, y: 1.0)
    gradientLayer.endPoint = CGPoint(x: 1.0, y: 1.0)

For more detail description refer Best Answer or you can follow CAGradientLayer From Apple

Hopes This is help for some one.

edited Aug 31 '18 at 09:47

answered Sep 29 '17 at 10:48

Jaywant Khedkar

5,941
2
44
55

Use following `startPoint` and `endPoint` for left to right gradient: `gradient.startPoint = CGPoint(x: 0.0, y: 0.5) gradient.endPoint = CGPoint(x: 1.0, y: 0.5)` and for top to bottom: `gradient.startPoint = CGPoint(x: 0.5, y: 0.0) gradient.endPoint = CGPoint(x: 0.5, y: 1.0)` – Neeraj Joshi Jul 25 '19 at 10:51

score 17 · Answer 9 · answered Feb 28 '19 at 13:42

It's easy

    // MARK: - Gradient
extension CAGradientLayer {
    enum Point {
        case topLeft
        case centerLeft
        case bottomLeft
        case topCenter
        case center
        case bottomCenter
        case topRight
        case centerRight
        case bottomRight
        var point: CGPoint {
            switch self {
            case .topLeft:
                return CGPoint(x: 0, y: 0)
            case .centerLeft:
                return CGPoint(x: 0, y: 0.5)
            case .bottomLeft:
                return CGPoint(x: 0, y: 1.0)
            case .topCenter:
                return CGPoint(x: 0.5, y: 0)
            case .center:
                return CGPoint(x: 0.5, y: 0.5)
            case .bottomCenter:
                return CGPoint(x: 0.5, y: 1.0)
            case .topRight:
                return CGPoint(x: 1.0, y: 0.0)
            case .centerRight:
                return CGPoint(x: 1.0, y: 0.5)
            case .bottomRight:
                return CGPoint(x: 1.0, y: 1.0)
            }
        }
    }
    convenience init(start: Point, end: Point, colors: [CGColor], type: CAGradientLayerType) {
        self.init()
        self.startPoint = start.point
        self.endPoint = end.point
        self.colors = colors
        self.locations = (0..<colors.count).map(NSNumber.init)
        self.type = type
    }
}

Use like this:-

let fistColor = UIColor.white
let lastColor = UIColor.black
let gradient = CAGradientLayer(start: .topLeft, end: .topRight, colors: [fistColor.cgColor, lastColor.cgColor], type: .radial)
gradient.frame = yourView.bounds
yourView.layer.addSublayer(gradient)

make (type: .axial) – Milan Savaliya M Oct 01 '22 at 16:21 — Milan Savaliya M, Oct 01 '22 at 16:21

Michael · Answer 10 · 2016-02-18T21:20:36.027

Extend UIView with this custom class.

GradientView.swift

import UIKit

class GradientView: UIView {

    // Default Colors
    var colors:[UIColor] = [UIColor.redColor(), UIColor.blueColor()]

    override func drawRect(rect: CGRect) {

        // Must be set when the rect is drawn
        setGradient(colors[0], color2: colors[1])
    }

    func setGradient(color1: UIColor, color2: UIColor) {

        let context = UIGraphicsGetCurrentContext()
        let gradient = CGGradientCreateWithColors(CGColorSpaceCreateDeviceRGB(), [color1.CGColor, color2.CGColor], [0, 1])!

        // Draw Path
        let path = UIBezierPath(rect: CGRectMake(0, 0, frame.width, frame.height))
        CGContextSaveGState(context)
        path.addClip()
        CGContextDrawLinearGradient(context, gradient, CGPointMake(frame.width / 2, 0), CGPointMake(frame.width / 2, frame.height), CGGradientDrawingOptions())
        CGContextRestoreGState(context)
    }

    override func layoutSubviews() {

        // Ensure view has a transparent background color (not required)
        backgroundColor = UIColor.clearColor()
    }

}

Usage

gradientView.colors = [UIColor.blackColor().colorWithAlphaComponent(0.8), UIColor.clearColor()]

Result

Is there any particular reason you're not calling `super.drawRect()`? — Rafał Sroka, Feb 25 '16 at 09:18
@Bearwithme no. Should work fine with `super.drawRect()` added. — Michael, Mar 23 '16 at 13:24
Better to add to top of GradientView.swift: `@IBInspectable var topColor: UIColor = UIColor.lightGrayColor()` `@IBInspectable var bottomColor: UIColor = UIColor.blueColor()` Then you can see at settings [Attribute Editor](http://i.stack.imgur.com/Em8Gn.jpg) — Dmitry Senashenko, Jul 05 '16 at 06:26

score 7 · Answer 11 · answered Oct 02 '18 at 02:59

7

Swift 4

Add a view outlet

@IBOutlet weak var gradientView: UIView!

Add gradient to the view

func setGradient() {
    let gradient: CAGradientLayer = CAGradientLayer()
    gradient.colors = [UIColor.red.cgColor, UIColor.blue.cgColor]
    gradient.locations = [0.0 , 1.0]
    gradient.startPoint = CGPoint(x: 0.0, y: 1.0)
    gradient.endPoint = CGPoint(x: 1.0, y: 1.0)
    gradient.frame = gradientView.layer.frame
    gradientView.layer.insertSublayer(gradient, at: 0)
}

answered Oct 02 '18 at 02:59

Vivek Jayakumar

71
1
2

2

If gradientView.layer.frame is not at (0,0), gradient layer is displaced. I would recommend using gradientView.layer.bounds . – vedrano Aug 10 '19 at 17:22

score 6 · Answer 12 · answered Oct 04 '16 at 12:06

6

This code will work with Swift 3.0

class GradientView: UIView {

    override open class var layerClass: AnyClass {
        get{
            return CAGradientLayer.classForCoder()
        }
    }

    required init?(coder aDecoder: NSCoder) {
        super.init(coder: aDecoder)
        let gradientLayer = self.layer as! CAGradientLayer
        let color1 = UIColor.white.withAlphaComponent(0.1).cgColor as CGColor
        let color2 = UIColor.white.withAlphaComponent(0.9).cgColor as CGColor
        gradientLayer.locations = [0.60, 1.0]
        gradientLayer.colors = [color2, color1]
    }
}

answered Oct 04 '16 at 12:06

Balaji Malliswamy

649
8
12

@Blahji Can you share example of usage..? And to use with a UILabel – Abirami Bala Oct 24 '16 at 11:36
Inserting a sublayer to a UILabel hides the text, so the best way to get what you want is to add the label and gradient layer to a UIView. – Balaji Malliswamy Oct 25 '16 at 12:51

Varun Naharia · Answer 13 · 2020-05-19T07:09:41.587

I mixed the Rohit Sisodia and MGM answers

// MARK: - Gradient

public enum CAGradientPoint {
    case topLeft
    case centerLeft
    case bottomLeft
    case topCenter
    case center
    case bottomCenter
    case topRight
    case centerRight
    case bottomRight
    var point: CGPoint {
        switch self {
        case .topLeft:
            return CGPoint(x: 0, y: 0)
        case .centerLeft:
            return CGPoint(x: 0, y: 0.5)
        case .bottomLeft:
            return CGPoint(x: 0, y: 1.0)
        case .topCenter:
            return CGPoint(x: 0.5, y: 0)
        case .center:
            return CGPoint(x: 0.5, y: 0.5)
        case .bottomCenter:
            return CGPoint(x: 0.5, y: 1.0)
        case .topRight:
            return CGPoint(x: 1.0, y: 0.0)
        case .centerRight:
            return CGPoint(x: 1.0, y: 0.5)
        case .bottomRight:
            return CGPoint(x: 1.0, y: 1.0)
        }
    }
}

extension CAGradientLayer {

    convenience init(start: CAGradientPoint, end: CAGradientPoint, colors: [CGColor], type: CAGradientLayerType) {
        self.init()
        self.frame.origin = CGPoint.zero
        self.startPoint = start.point
        self.endPoint = end.point
        self.colors = colors
        self.locations = (0..<colors.count).map(NSNumber.init)
        self.type = type
    }
}

extension UIView {

    func layerGradient(startPoint:CAGradientPoint, endPoint:CAGradientPoint ,colorArray:[CGColor], type:CAGradientLayerType ) {
        let gradient = CAGradientLayer(start: .topLeft, end: .topRight, colors: colorArray, type: type)
        gradient.frame.size = self.frame.size
        self.layer.insertSublayer(gradient, at: 0)
    }
}

To Use write:-

        btnUrdu.layer.cornerRadius = 25
        btnUrdu.layer.masksToBounds = true
        btnUrdu.layerGradient(startPoint: .centerRight, endPoint: .centerLeft, colorArray: [UIColor.appBlue.cgColor, UIColor.appLightBlue.cgColor], type: .axial)

Output:

score 3 · Answer 14 · answered Apr 30 '15 at 09:07

if you want to use HEX instead of RGBA, just drag a new empty .swift and add below mentioned code:

     import UIKit

    extension UIColor {
        convenience init(rgba: String) {
            var red:   CGFloat = 0.0
            var green: CGFloat = 0.0
            var blue:  CGFloat = 0.0
            var alpha: CGFloat = 1.0

            if rgba.hasPrefix("#") {
                let index   = advance(rgba.startIndex, 1)
                let hex     = rgba.substringFromIndex(index)
                let scanner = NSScanner(string: hex)
                var hexValue: CUnsignedLongLong = 0
                if scanner.scanHexLongLong(&hexValue) {
                    switch (count(hex)) {
                    case 3:
                        red   = CGFloat((hexValue & 0xF00) >> 8)       / 15.0
                        green = CGFloat((hexValue & 0x0F0) >> 4)       / 15.0
                        blue  = CGFloat(hexValue & 0x00F)              / 15.0
                    case 4:
                        red   = CGFloat((hexValue & 0xF000) >> 12)     / 15.0
                        green = CGFloat((hexValue & 0x0F00) >> 8)      / 15.0
                        blue  = CGFloat((hexValue & 0x00F0) >> 4)      / 15.0
                        alpha = CGFloat(hexValue & 0x000F)             / 15.0
                    case 6:
                        red   = CGFloat((hexValue & 0xFF0000) >> 16)   / 255.0
                        green = CGFloat((hexValue & 0x00FF00) >> 8)    / 255.0
                        blue  = CGFloat(hexValue & 0x0000FF)           / 255.0
                    case 8:
                        red   = CGFloat((hexValue & 0xFF000000) >> 24) / 255.0
                        green = CGFloat((hexValue & 0x00FF0000) >> 16) / 255.0
                        blue  = CGFloat((hexValue & 0x0000FF00) >> 8)  / 255.0
                        alpha = CGFloat(hexValue & 0x000000FF)         / 255.0
                    default:
                        print("Invalid RGB string, number of characters after '#' should be either 3, 4, 6 or 8")
                    }
                } else {
                    println("Scan hex error")
                }
            } else {
                print("Invalid RGB string, missing '#' as prefix")
            }
            self.init(red:red, green:green, blue:blue, alpha:alpha)
        }
}

similarly, drag another empty .swift file and add below mentioned code:

    class Colors {
    let colorTop = UIColor(rgba: "##8968CD").CGColor
    let colorBottom = UIColor(rgba: "#5D478B").CGColor

    let gl: CAGradientLayer

    init() {
        gl = CAGradientLayer()
        gl.colors = [ colorTop, colorBottom]
        gl.locations = [ 0.0, 1.0]
    }
}

after that in view controller, under class instantiate your 'Color' class like this:

let colors = Colors()

add a new function:

func refresh() {
        view.backgroundColor = UIColor.clearColor()
        var backgroundLayer = colors.gl
        backgroundLayer.frame = view.frame
        view.layer.insertSublayer(backgroundLayer, atIndex: 0)
    }

state that function in viewDidLoad:

refresh()

you're done :)) using HEX is way too easy if compared to RGBA. :D

score 3 · Answer 15 · answered Sep 13 '16 at 03:27

Swift 3 - Uses only textures and SKSpriteNode, doesn't require UIView

import Foundation
import SpriteKit

class GradientSpriteNode : SKSpriteNode
{
    convenience init(size: CGSize, colors: [UIColor], locations: [CGFloat])
    {
        let texture = GradientSpriteNode.texture(size: size, colors: colors, locations: locations)
        self.init(texture: texture, color:SKColor.clear, size: texture.size())
    }

    private override init(texture: SKTexture!, color: SKColor, size: CGSize) {
        super.init(texture: texture, color: color, size: size)
    }

    required init?(coder aDecoder: NSCoder) {
        fatalError("init(coder:) has not been implemented")
    }

    private static func texture(size: CGSize, colors: [UIColor], locations: [CGFloat]) -> SKTexture
    {
        UIGraphicsBeginImageContext(size)
        let context = UIGraphicsGetCurrentContext()!
        let gradient = CGGradient(colorsSpace: CGColorSpaceCreateDeviceRGB(), colors: colors.map{$0.cgColor} as CFArray, locations: locations)!
        context.drawLinearGradient(gradient, start: CGPoint(x: size.width / 2, y: 0), end: CGPoint(x: size.width / 2, y: size.height), options: CGGradientDrawingOptions())
        let image = UIGraphicsGetImageFromCurrentImageContext()
        UIGraphicsEndImageContext()
        return SKTexture(image: image!)

    }
}

Usage:

let gradient = GradientSpriteNode(
        size: CGSize(width: 100, height: 100),
        colors: [UIColor.red, UIColor.blue],
        locations: [0.0, 1.0])
addChild(gradient)

what is the performance of spritekitnode versus cagradientlayer? having to render the image seems like it would be slower. — μολὼν.λαβέ, Aug 15 '17 at 14:23
I don't know off the top of my head, but usually the ca** classes are much much more performant than the sprite kit ones. — texuf, Aug 16 '17 at 18:14

score 3 · Answer 16 · answered Jun 23 '18 at 07:51

I wanted to add a gradient to a view, and then anchor it using auto-layout.

    class GradientView: UIView {

    private let gradient: CAGradientLayer = {
        let layer = CAGradientLayer()
        let topColor: UIColor = UIColor(red:0.98, green:0.96, blue:0.93, alpha:0.5)
        let bottomColor: UIColor = UIColor.white
        layer.colors = [topColor.cgColor, bottomColor.cgColor]
        layer.locations = [0,1]
        return layer
    }()

    init() {
        super.init(frame: .zero)
        gradient.frame = frame
        layer.insertSublayer(gradient, at: 0)
    }

    required init?(coder aDecoder: NSCoder) {
        fatalError("init(coder:) has not been implemented")
    }

    override func layoutSubviews() {
        super.layoutSubviews()
        gradient.frame = bounds

    }
}

score 3 · Answer 17 · answered Feb 18 '19 at 13:10

Use below code :

extension UIView {
func applyGradient(colours: [UIColor]) -> Void {
 let gradient: CAGradientLayer = CAGradientLayer()
 gradient.frame = self.bounds
 gradient.colors = colours.map { $0.cgColor }
 gradient.startPoint = CGPoint(x : 0.0, y : 0.5)
 gradient.endPoint = CGPoint(x :1.0, y: 0.5)
 self.layer.insertSublayer(gradient, at: 0)
 }
}

call this function like :

  self.mainView.applyGradient(colours: [.green, .blue])

score 3 · Answer 18 · answered Jul 24 '20 at 11:20

Xcode 11 | Swift 5

If anybody is looking for a quick and easy way to add a gradient to a view:

extension UIView {

    func addGradient(colors: [UIColor] = [.blue, .white], locations: [NSNumber] = [0, 2], startPoint: CGPoint = CGPoint(x: 0.0, y: 1.0), endPoint: CGPoint = CGPoint(x: 1.0, y: 1.0), type: CAGradientLayerType = .axial){

        let gradient = CAGradientLayer()

        gradient.frame.size = self.frame.size
        gradient.frame.origin = CGPoint(x: 0.0, y: 0.0)

        // Iterates through the colors array and casts the individual elements to cgColor
        // Alternatively, one could use a CGColor Array in the first place or do this cast in a for-loop
        gradient.colors = colors.map{ $0.cgColor }

        gradient.locations = locations
        gradient.startPoint = startPoint
        gradient.endPoint = endPoint

        // Insert the new layer at the bottom-most position
        // This way we won't cover any other elements
        self.layer.insertSublayer(gradient, at: 0)
    }
}

Examples on how to use the extension:

// Testing
view.addGradient()

// Two Colors
view.addGradient(colors: [.init(rgb: 0x75BBDB), .black], locations: [0, 3])

// Full Blown
view.addGradient(colors: [.init(rgb: 0x75BBDB), .black], locations: [0, 3], startPoint: CGPoint(x: 0.0, y: 1.5), endPoint: CGPoint(x: 1.0, y: 2.0), type: .axial)

Optionally, use the following to input hex numbers .init(rgb: 0x75BBDB)

extension UIColor {
   convenience init(red: Int, green: Int, blue: Int) {
       self.init(red: CGFloat(red) / 255.0, green: CGFloat(green) / 255.0, blue: CGFloat(blue) / 255.0, alpha: 1.0)
   }

   convenience init(rgb: Int) {
       self.init(
           red: (rgb >> 16) & 0xFF,
           green: (rgb >> 8) & 0xFF,
           blue: rgb & 0xFF
       )
   }
}

Anyone with any corner radius going on would benefit from: `gradient.cornerRadius = self.layer.cornerRadius` - Just be careful not to apply the corner radius after the gradient. — paul_f, Nov 26 '21 at 16:05

Alexandr Arsenyuk · Answer 19 · 2019-07-16T08:26:03.677

2

To add gradient into layer, add:

let layer = CAGradientLayer()
layer.frame = CGRect(x: 64, y: 64, width: 120, height: 120)
layer.colors = [UIColor.red.cgColor, UIColor.blue.cgColor]
view.layer.addSublayer(layer)

edited Jul 16 '19 at 08:26

answered Jul 16 '19 at 06:27

Alexandr Arsenyuk

85
1
4

Please do add some explanation with it too. – surajs1n Jul 16 '19 at 06:47

score 1 · Answer 20 · answered Sep 01 '16 at 08:30

Here's a swift extension where you can pass any amount of arbitrary colors. It will remove any previous gradients before inserting one and it will return the newly inserted gradient layer for further manipulation if needed:

    extension UIView {

    /**
     Given an Array of CGColor, it will:
        - Remove all sublayers of type CAGradientLayer.
        - Create and insert a new CAGradientLayer.

     - Parameters:
        - colors: An Array of CGColor with the colors for the gradient fill

     - Returns: The newly created gradient CAGradientLayer
     */
    func layerGradient(colors c:[CGColor])->CAGradientLayer {
        self.layer.sublayers = self.layer.sublayers?.filter(){!($0 is CAGradientLayer)}
        let layer : CAGradientLayer = CAGradientLayer()
        layer.frame.size = self.frame.size
        layer.frame.origin = CGPointZero
        layer.colors = c
        self.layer.insertSublayer(layer, atIndex: 0)
        return layer
    }
}

Dupinder kaur · Answer 21 · 2016-12-13T09:23:23.990

Just Specify the Frame of the View, where you want to show the gradient color.

let firstColor =  UIColor(red: 69/255, green: 90/255, blue: 195/255, alpha: 1.0).CGColor

 let secondColor = UIColor(red: 230/255, green: 44/255, blue: 75/255, alpha: 1.0).CGColor

    let gradientLayer = CAGradientLayer()
    gradientLayer.colors = [ firstColor, secondColor]
    gradientLayer.locations = [ 0.0, 1.0]
    gradientLayer.frame = CGRectMake(0, 0, 375, 64)// You can mention frame here

    self.view.layer.addSublayer(gradientLayer)

Gene Bo · Answer 22 · 2017-07-20T21:11:49.400

Here's a variation for setting this up in a reusable Util class file

In your Xcode project:

Create a new Swift class call it UI_Util.swift, and populate it as follows:

import Foundation
import UIKit

class UI_Util {

    static func setGradientGreenBlue(uiView: UIView) {

        let colorTop =  UIColor(red: 15.0/255.0, green: 118.0/255.0, blue: 128.0/255.0, alpha: 1.0).cgColor
        let colorBottom = UIColor(red: 84.0/255.0, green: 187.0/255.0, blue: 187.0/255.0, alpha: 1.0).cgColor

        let gradientLayer = CAGradientLayer()
        gradientLayer.colors = [ colorTop, colorBottom]
        gradientLayer.locations = [ 0.0, 1.0]
        gradientLayer.frame = uiView.bounds

        uiView.layer.insertSublayer(gradientLayer, at: 0)
    }
}

Now you can call the function from any ViewController like so:

class AbcViewController: UIViewController {

    override func viewDidLoad() {
        super.viewDidLoad()
        UI_Util.setGradientGreen(uiView: self.view)
    }

Thanks to katwal-Dipak's answer for the function code

Hardik Thakkar · Answer 23 · 2018-05-29T10:19:26.583

For swift to apply CAGradientLayer to any object (Horizontal and vertical)

func makeGradientColor(`for` object : AnyObject , startPoint : CGPoint , endPoint : CGPoint) -> CAGradientLayer {
    let gradient: CAGradientLayer = CAGradientLayer()

    gradient.colors = [(UIColor(red: 59.0/255.0, green: 187.0/255.0, blue: 182.0/255.0, alpha: 1.00).cgColor), (UIColor(red: 57.0/255.0, green: 174.0/255.0, blue: 236.0/255.0, alpha: 1.00).cgColor)]
    gradient.locations = [0.0 , 1.0]

    gradient.startPoint = startPoint
    gradient.endPoint = endPoint
    gradient.frame = CGRect(x: 0.0, y: 0.0, width: object.frame.size.width, height: object.frame.size.height)
    return gradient
}

How to use

let start : CGPoint = CGPoint(x: 0.0, y: 1.0)
let end : CGPoint = CGPoint(x: 1.0, y: 1.0)
let gradient: CAGradientLayer = self.makeGradientColor(for: vwTop, startPoint: start, endPoint: end)
vwTop.layer.insertSublayer(gradient, at: 0)

let start1 : CGPoint = CGPoint(x: 1.0, y: 1.0)
let end1 : CGPoint = CGPoint(x: 1.0, y: 0.0)
let gradient1: CAGradientLayer = self.makeGradientColor(for: vwTop, startPoint: start1, endPoint: end1)
vwBottom.layer.insertSublayer(gradient1, at: 0)

You can check output here

Abdulmoiz Ahmer · Answer 24 · 2019-02-08T10:56:37.900

There is a library called Chameleon (https://github.com/viccalexander/Chameleon) which one can use for gradient colors. It even has styles of gradient to implement. This is how you can add it in swift 4 podfile pod 'ChameleonFramework/Swift', :git => 'https://github.com/ViccAlexander/Chameleon.git', :branch => 'wip/swift4'

import ChameleonFramework

let colors:[UIColor] = [
  UIColor.flatPurpleColorDark(),
  UIColor.flatWhiteColor()
]
view.backgroundColor = GradientColor(.TopToBottom, frame: view.frame, colors: colors)

score 0 · Answer 25 · edited Jan 31 '17 at 19:44

Cleaner code that lets you pass any UIColor to an instance of the GradientLayer class:

class GradientLayer {

    let gradientLayer: CAGradientLayer
    let colorTop: CGColor
    let colorBottom: CGColor

    init(colorTop: UIColor, colorBottom: UIColor) {
        self.colorTop = colorTop.CGColor
        self.colorBottom = colorBottom.CGColor
        gradientLayer = CAGradientLayer()
        gradientLayer.colors = [colorTop, colorBottom]
        gradientLayer.locations = [0.0, 1.0]
    }
}

score 0 · Answer 26 · edited May 29 '18 at 09:47

If you have view Collection (Multiple View) do this

  func setGradientBackground() {
    let v:UIView
    for v in viewgradian
    //here viewgradian is your view Collection Outlet name
    {
        let layer:CALayer
        var arr = [AnyObject]()
        for layer in v.layer.sublayers!
        {
           arr.append(layer)
        }

        let colorTop = UIColor(red: 216.0/255.0, green: 240.0/255.0, blue: 244.0/255.0, alpha: 1.0).cgColor
        let colorBottom = UIColor(red: 255.0/255.0, green: 255.0/255.0, blue: 255.0/255.0, alpha: 1.0).cgColor
        let gradientLayer = CAGradientLayer()
        gradientLayer.colors = [ colorBottom, colorTop]
        gradientLayer.startPoint = CGPoint(x: 1.0, y: 0.0)
        gradientLayer.endPoint = CGPoint(x: 0.0, y: 1.0)
        gradientLayer.frame = v.bounds
        v.layer.insertSublayer(gradientLayer, at: 0)
    }
}

Tarik · Answer 27 · 2018-01-12T06:20:27.023

Easy to use extension on swift 3

extension CALayer {
    func addGradienBorder(colors:[UIColor] = [UIColor.red,UIColor.blue], width:CGFloat = 1) {
        let gradientLayer = CAGradientLayer()
        gradientLayer.frame =  CGRect(origin: .zero, size: self.bounds.size)
        gradientLayer.startPoint = CGPoint(x:0.0, y:0.5)
        gradientLayer.endPoint = CGPoint(x:1.0, y:0.5)
        gradientLayer.colors = colors.map({$0.cgColor})

        let shapeLayer = CAShapeLayer()
        shapeLayer.lineWidth = width
        shapeLayer.path = UIBezierPath(rect: self.bounds).cgPath
        shapeLayer.fillColor = nil
        shapeLayer.strokeColor = UIColor.black.cgColor
        gradientLayer.mask = shapeLayer

        self.addSublayer(gradientLayer)
    }
}

use to your view, example

yourView.addGradienBorder(color: UIColor.black, opacity: 0.1, offset: CGSize(width:2 , height: 5), radius: 3, viewCornerRadius: 3.0)

score 0 · Answer 28 · answered Feb 05 '20 at 03:56

For those wanting an Objective C version of the answer. Tested and works on iOS13

// Done here so that constraints have completed and the frame is correct.
- (void) viewDidLayoutSubviews {
    [super viewDidLayoutSubviews];
    UIColor *colorTop = [UIColor colorWithRed:(CGFloat)192.0/255.0 green: 38.0/255.0 blue: 42.0/255.0 alpha:1.0];
    UIColor *colorBottom = [UIColor colorWithRed: 35.0/255.0 green: 2.0/255.0 blue: 2.0/255.0 alpha: 1.0];
    CAGradientLayer *gl = [CAGradientLayer new];
    [gl setColors:@[(id)[colorTop CGColor], (id)[colorBottom CGColor]]];
    [gl setLocations:@[@0.0f, @1.0f]];
    self.view.backgroundColor = [UIColor clearColor];
    CALayer *backgroundLayer = gl;
    backgroundLayer.frame = self.view.frame;
    [self.view.layer insertSublayer:backgroundLayer atIndex:0];
}

score 0 · Answer 29 · answered Mar 20 '20 at 20:25

0

One thing I noticed is you can't add a gradient to a UILabel without clearing the text. One simple workaround is to use a UIButton and disable user interaction.

answered Mar 20 '20 at 20:25

Henry

3,447
1
15
12

skmalm · Answer 30 · 2020-04-18T18:01:16.180

SwiftUI: You can use the LinearGradient struct as the first element in a ZStack. As the "bottom" of the ZStack, it will serve as the background color. AngularGradient and RadialGradient are also available.

import SwiftUI

struct ContentView: View {
    var body: some View {
        ZStack {
            LinearGradient(gradient: Gradient(colors: [.red, .blue]), startPoint: .top, endPoint: .bottom)
                .edgesIgnoringSafeArea(.all)
            // Put other content here; it will appear on top of the background gradient
        }
    }
}

How to Apply Gradient to background view of iOS Swift App

30 Answers30

Linked

Related
